Franke FAK 607 - Characteristics

EN
5
5
CHARACTERISTICS
Dimensions
598 / 898
126
81
Min.1305 - Max.1670
Components
Ref. Q.ty Product Components
1 1 Hood Body, complete with: Controls, Light, Blower,
Filters
2.1 1 Upper Section
2.2 1 Lower Section
8 1 Directional Air Outlet grille
9 1 Flange
14.1 2 Air Outlet Connection Extension
15 1 Air Outlet Connection
16 1 Filter cover
Ref. Q.ty Installation Components
7.2.1 2 Upper Chimney Section Fixing Brackets
7.3 1 Air Outlet Connection Support
11 6 Wall Plugs
11a 2 Wall Plugs SB 12/10
12a 6 Screws 4,2 x 44,4
12c 10 Screws 2,9 x 6,5
12d 2 Screws 2,9 x 9,5
Q.ty Documentation
1 Instruction Manual
1
11
12a
16
12c
12d
8
9
11a
2.1
2.2
12c
12a
7.2.1 11
7.3
14.1
15
