6 | Installation Franke Kaffeemaschinen AG
34 User manual SB1200 FM CM
SB1200 FM CM with UT12 cooling unit - front/side view
NOTICE
Overheating damage
If the clearances around and above the machine are too small, heat may accumulate in the machine and lead to
faults.
a) Maintain the prescribed installation dimensions and clearances.
b) Take care to ensure that the clearance spaces are not blocked.
Minimum clearances
– To the rear panel: 50 mm
– Above: 200 mm (for filling and removal of the bean hopper)
– To the right: 100 mm (for opening the door)
Optional adjustable feet can be used to compensate for unevenness or differences in height.
Openings in counter top
The following illustrations are examples. Please refer to the design data for the details matching your configuration.
