Franke FCS4050 - Page 41

Franke Kaffeemaschinen AG Filling and emptying | 7
User manual SB1200 FM CM 41
7.3.2 UT40 cooling unit
NOTICE
Damage or breakage of grate
If the maximum load capacity of the grate in the cooling unit is exceeded, this can lead to damage or breakage.
a) Ensure that the maximum load capacity of the grate (22kg) is not exceeded.
1. Open the cooling unit door.
2. Switch on the cooling unit.
ð The current cooling chamber temperature is
displayed.
3. Disconnect the plug-in couplings from the con-
tainer and connect to the pump module.
4. Remove the container.
5. Remove the container lid.
6. Fill the container with cold milk or cold media.
7. Fit the container lid on the container.
8. Connect the plug-in coupling to the container.
9. Slide the container all the way into the cooling
chamber.
10. Close the cooling unit door.
