7 | Filling and emptying Franke Kaffeemaschinen AG
44 User manual SB1200 FM CM
1. Pull the locking slide towards the front up to the
stop.
2. Lift and remove the bean hopper.
3. If necessary, adjust the grind coarseness using
the grinder adjustment wrench.
ð Turn counterclockwise for a finer grind.
ð Turn clockwise for a coarser grind.
4. Attach the bean hopper.
5. Check the grind produced and adjust if neces-
sary.
6. Attach the bean hopper.
7. Push the locking slide all the way in.
NOTICE
Impairment of function
If the bean hopper and powder hopper are not locked correctly, the function of the coffee machine and the product
quality may be impaired.
a) Push the locking slide all the way in.
