4
4
4
44 4 4
01 02 03
05 06
04
07
4
04 05 0807
4 4 4 4
06
4
Start-up, Filling and Emptying
Page 23
Close the door.Push the water tank into the
machine until it hits the stop.
Insert the water tank to the
half-way point and seal with the
cover.
Empty, clean and dry the water
tank.
Fold open the handle.
Remove water tank.
Emptying the coffee bean hopper
NOTICE
The quality of the coffee may be impaired!
Dry the coffee bean hopper well after cleaning it.
There must not be any residue from cleaning agents.
Emptying the water tank (cont.)
Seal the coffee bean hopper
with the cover.
Close the door.
Empty, clean and dry the bean
hopper.
Remove the cover.
Push powder container forward
to limit stop and remove by
pulling straight up.
Pull red unlocking lever for-
ward.
Press the release button and
open the door.
To Next Page
