FIGURE D
CONTINUED - STABILIZER KIT
• Attach the remaining arm to the other side.
NOTE: There is an adjustment to the outer
end of the stays so as to align the knob/
screw connection with the umbrella arms.
• You may need to loosen the central
threaded stainless steel screw and
adjust up or down the mast until you
have applied a little upward tension on
the umbrella arms. Tighten this screw
in position (Figure D for umbrella with
stabilizer kit correctly fitted).
• CAUTION: Do not over tension as this may
distort the umbrella arms. Reverse the
process to remove the stabilizer kit. The
stabilizer kit must be removed to close the
umbrella or tilt the canopy.
Important:
Your Eclipse Cantilever Umbrella, even
when fitted with the stay kit, is not a
permanent, all-weather structure. The
umbrella should be closed and folded
when not in use and never left open when
unattended or in strong winds.
