Installing to the 550NGU: Galvanized Steel Base ships ready to use. The
Spigot must be bolted to the universal deck plate already installed on the aluminum lid with
the hardware supplied. Match threaded holes on the Spigot with the corresponding holes on
the universal deck plate.
Your umbrella comes with a spigot. Once you have assembled the base according to the
instructions below, attach the spigot to the base using the supplied Allen key and bolts. Once
the base is fully secured, lift the umbrella on to the top of the spigot. This is recommended
as a two man operation.
WEIGHTED BASE INSTALLATION
Important: All plates are stackable. There are 2 sets of holes on each plate - naked
holes and threaded holes. Be sure to use the threaded holes on the bottom plate ONLY. Line
up the naked holes on the upper plates and bolt your Stem through to the threaded holes on
the bottom plate.
Note: The 40G three stack is the maximum stack available at 555 lbs. This is required for
the Eclipse Cantilever Umbrella.
Installing to 40G+40+40: When installing your umbrella on a Galvanized
Plate Stack, rotate the Spigot to match the threaded holes through the top and bottom
plates. The diameter of the countersunk holes in the Spigot is .5”, use M10/M12 bolts included
with your umbrella.
TWO UMBRELLA BASE INSTALLATION ALTERNATIVES
19 |
