Why is the pressure low on my Franklin Electric SUBDRIVE UTILITY UT3P?
If you're experiencing low pressure with your Franklin Electric DC Drives, first adjust the pressure sensor and check the pump rotation. Also, check the frequency at maximum flow and verify the maximum pressure. A high ambient or drive temperature can also cause the drive to reduce power, leading to reduced performance.
What to do if there is high pressure with Franklin Electric SUBDRIVE UTILITY UT3P DC Drives?
To address high pressure with your Franklin Electric DC Drives, start by adjusting the pressure sensor. If that doesn't resolve the issue, remove the sensor wire at the Input Board. If the drive stops running, the wire may be shorted; verify its condition and repair or replace it if necessary. However, if the drive continues to run after removing the sensor wire, the drive may need replacement.
How to fix pressure fluctuations in Franklin Electric SUBDRIVE UTILITY UT3P DC Drives?
If you observe pressure fluctuations or poor regulation with your Franklin Electric DC Drives, ensure correct pressure sensor placement and settings. The tank might be too small for the system flow. Disconnect power and check the pressure gauge for any drop. If applicable, set the system deeper in the well or tank, and consider installing a flow sleeve with an airtight seal around the drop pipe and cable. If the fluctuation occurs only on branches before the sensor, enable Steady Flow. Finally, adjust the System Response value.
What to do if Franklin Electric SUBDRIVE UTILITY UT3P DC Drives run on and won't stop pump?
If your Franklin Electric DC Drives pump won’t stop running, check the frequency at low flows as the pressure setting may be too close to the pump's maximum head. Verify the precharge at 70% if the tank size is larger than the minimum, and consider increasing the precharge up to 85%. Also, confirm that the system will build and hold pressure. Enabling bump and/or aggressive bump features and increasing the minimum frequency might also help resolve the issue.
How to reduce audible noise from Franklin Electric SUBDRIVE UTILITY UT3P DC Drives?
If you're experiencing excessive fan noise with your Franklin Electric DC Drives, try replacing the fan. If the fan noise is normal, consider relocating the drive to a more remote area. For hydraulic noise, try adjusting the depth of the pump. Ensure the pressure tank is located at the entrance of the water line into the house.
How to prevent RFI-EMI interference in Franklin Electric DC Drives?
To minimize RFI-EMI interference with your Franklin Electric DC Drives, adhere to grounding and wire routing recommendations. If the issue persists, consider using an additional external filter.
How to resolve intermittent operation of Franklin Electric DC Drives?
To resolve intermittent operation of your Franklin Electric DC Drives or pump, wire the drive directly to the pump/motor, bypassing the pump pressure switch.
General| Category | DC Drives |
|---|---|
| Model | SUBDRIVE UTILITY UT3P |
| Horsepower | 3 HP |
| Enclosure | NEMA 3R |
| Frequency | 50/60 Hz |
| Cooling Method | Fan Cooled |
| Control Method | Sensorless Vector |
| Communication Interface | Modbus RTU |
| Operating Temperature | -10°C to 50°C (14°F to 122°F) |
| Humidity | 95% RH (non-condensing) |
| Altitude | 1000m |
| Storage Temperature | -20°C to 65°C |
Explains the different types of safety messages used in the manual, including DANGER, WARNING, CAUTION, and NOTICE.
Provides essential prerequisites and qualifications for personnel, emphasizing qualified installer requirements.
Details specific safety warnings and precautions for the SubDrive Utility UT3P, focusing on electrical hazards.
Overview of the SubDrive Utility UT3P, its purpose, and key configuration, operation, and protection features.
Details model numbers for submersible and surface applications and their compatibility.
Guidelines for selecting pump size and recommendations for choosing a generator to power the drive.
Instructions for safely transporting and storing the drive unit to prevent damage.
Steps for safely removing the drive from packaging and identifying all included components.
Key factors to consider before installing the drive system, including intended function and hardware.
Illustrates a typical system arrangement for submersible pump constant pressure applications.
Illustrates a typical system arrangement for surface pump pressure boosting applications.
Provides recommendations for sizing pressure tanks and supply pipes for optimal system performance.
Specifies operating temperature and environmental conditions required for the drive.
Guidelines for installing the drive in outdoor environments, including NEMA 3R rating considerations.
Details physical dimensions and step-by-step instructions for securely mounting the drive unit.
Recommendations for wiring the drive and routing cables to ensure performance and prevent interference.
Information on required circuit protection and selecting appropriate wire gauges based on motor HP.
Charts detailing maximum allowable motor cable lengths based on wire size and voltage drop.
Diagram and information regarding conduit entry points and sizing for the drive enclosure.
Safety warnings and procedures for making high voltage connections to the drive.
Requirements and procedures for proper grounding of the drive system for safety and performance.
Detailed instructions for connecting the power supply and motor leads to the drive terminals.
Instructions for wiring pressure sensors and transducers to the drive's control circuit.
How to configure motor type, phase, horsepower, and surface amps using DIP switches.
How to select pressure input and adjust pressure settings for sensors and transducers.
How to configure system response, drawdown, minimum frequency, and underload sensitivity.
Deep set, steady flow, tank size, and bump mode adjustments for fine-tuning performance.
Overview of control functions and explanation of the drive's status lights and their meaning.
Information on drive status indicators, fault event logging, and automatic reset behavior.
Details on built-in protection features like over-temperature foldback and broken pipe detection.
General guide for diagnosing and resolving system issues, including fault history download.
Table detailing fault codes, their possible causes, and corrective actions.
Troubleshooting guide based on observed system conditions, symptoms, and no-water scenarios.
Addresses issues like pressure fluctuations, run-on, tripping, low/high pressure, noise, and interference.
Procedures for replacing the drive's cooling fan and cleaning or replacing air intake screens.
Procedure to check the currently installed firmware version using the drive's LEDs.
Step-by-step instructions for updating the drive's firmware using a USB device.
Lists key electrical, dimensional, and operating specifications for the SubDrive Utility UT3P.
Details available accessories, their part numbers, and relevant safety and enclosure standards.
Outlines the terms, limitations, exclusions, and conditions of the product's limited warranty.
