INSTALLATION AND SETUP
Programming: Advanced Setup > Motor Protection > Power
22
Programming: Advanced Setup > Motor Protection > Power
440 RW N Time to Trip 1 to 120; default = 10 Undervoltage Delay Time in seconds
441 RW N Fault Reset Type 0 - Manual
1 - Automatic (default)
Undervoltage Reset Method
442 RW N Reset Retries 1 to 10; default = 3 When automatic reset is enabled, this sets how many
times to attempt resetting the fault.
443 RW N Reset Delay 1 to 43,200; default = 900 The number of seconds between automatic resets.
Voltage Unbalance Menu
444 RW N Trip/Alarm 0 - Off
1 - Fault and Alarm (default)
2 - Alarm Only
Choose the type of response for when a Voltage Unbal-
ance is detected.
445 RW N Unbalance Level 1% to 25%; default = 1% Percentage of voltage unbalance detected to cause a
fault condition.
446 RW N Time to Trip 1 to 120; default = 10 Amount of time in seconds for the unbalanced voltage
situation to subside. If exceeded, then trigger the fault.
447 RW N Fault Reset Type 0 - Manual
1 - Automatic (default)
Choose the Voltage Unbalance reset method.
448 RW N Reset Retries 1 to 10; default = 3 When automatic reset is enabled, this sets how many
times to attempt resetting the fault.
449 RW N Reset Delay 1 to 43,200; default = 900 The number of seconds between automatic resets.
Phase Reversal Menu
450 RW N Trip/Alarm 0 - Off
1 - Fault and Alarm (default)
2 - Alarm Only
Choose the type of response for when a voltage phase
reversal condition is detected.
451 RW N Phase Order 0 - A B C (default)
1 - A C B
Phase Order
Voltage Loss Menu
487 RW N Fault Reset Type 0 - Manual (default)
1 - Automatic
Choose whether the Voltage Loss fault reset is performed
manually or automatically.
488 RW N Reset Retries 1 to 10; default = 3 When automatic reset is enabled, this sets how many
times to attempt resetting the fault.
489 RW N Reset Delay 1 to 43,200; default = 900 The number of seconds between automatic resets.
Mod
bus
RW RC Display Name Range Description
Mod
bus
RW RC Display Name Range Description
Underpower menu
452 RW N Trip/Alarm 0 - Off
1 - Fault and Alarm (default)
2 - Alarm Only
Underpower Protection Enable
453 RW N Underpower Level 1 to 99; default = 50/65 Underpower Level Percentage
SMS default = 65
Reduced Voltage SMS default = 50
454 RW N Underpower Delay 1 to 120; default = 2/3 Underpower Delay Time in seconds
SMS default = 3
Reduced Voltage SMS default = 2
