INSTALLATION AND SETUP
Programming: Advanced Setup > Motor Protection > System
23
Programming: Advanced Setup > Motor Protection > System
455 RW N Underpower Reset 0 - Manual
1 - Automatic
2 - Well Recovery (Submers-
ible Pump only)
Underpower Reset Method
When set to well recovery, the SubMonitor Connect
infinitely resets an Underpower fault condition based on
the user-selected reset delay.
456 RW N Underpower Retry 1 to 10; default = 3 Underpower Automatic Reset Attempts
457 RW N Underpower Reset
Delay
1 to 43,200; default = 900 Underpower Reset Delay in seconds
Overpower menu
458 RW N Trip/Alarm 0 - Off
1 - Fault and Alarm (default)
2 - Alarm Only
Choose the type of response for when an Overpower con-
dition is detected.
459 RW N Overpower Level 101 to 200; default = 125 Over Power Level Percentage
460 RW N Time to Trip 1 to 120; default = 3 Over Power Delay Time in seconds
461 RW N Fault Reset Type 0 - Manual
1 - Automatic (default)
Over Power Reset Method
462 RW N Reset Retries 1 to 10; default = 3 Over Power Automatic Reset Attempts
463 RW N Reset Delay 1 to 43,200; default = 900 Over Power Reset Delay in seconds
Negative Power menu
464 RW N Trip/Alarm 0 - Off (default)
1 - Fault and Alarm
2 - Alarm Only
Choose the type of response for when Negative Power is
detected.
Underpower menu
452 Trip/Alarm 0 - Off
1 - Fault and Alarm (default)
2 - Alarm Only
Choose the type of response for when Underpower is
detected.
453 Underpower Level 101 to 200; default = 125 Underpower Level Percentage
454 Time to Trip 1 to 120; default = 3 Underpower Delay Time in seconds
455 Fault Reset Type 0 - Manual
1 - Automatic (default)
Over Power Reset Method
456 Reset Retries 1 to 10; default = 3 Underpower Automatic Reset Attempts
457 Reset Delay 1 to 43,200; default = 900 Underpower Reset Delay in seconds
Mod
bus
RW RC Display Name Range Description
Mod
bus
RW RC Display Name Range Description
Insulation Check menu
465 RW N Trip/Alarm 0 - Off (default)
1 - Fault and Alarm
2 - Alarm Only
Insulation Check Enable. This measures an approximate
resistance between the W circuit and earth ground.
466 RW N Fault Resistance 1 to 2000; default = 500
Insulation Resistance Fault Level
467 RW N Alarm Resistance 1 to 3000; default = 1000
Insulation Resistance Alarm Level
SubTemp menu
468 RW N Trip/Alarm 0 - Off (default)
1 - Fault and Alarm
2 - Alarm Only
SubTemp Motor Protection Enable
469 RW N Trip Temp 0 to 150; default = 40
SubTemp Fault Trip Temperature setting in °C
470 RW N Alarm Temp 0 to 150; default = 30
SubTemp Alarm Trip Temperature setting in °C
