3
Components
4 Line
Digital Display
Fault LIght (Display)
Menu Selector
Switch
Alarm Circuit
Terminals
Control Circuit
Terminals
Reset Switch
Inputs (L1, L2, L3)
Fault Light (Base)
Detachable Display Unit
Base Unit
Integrated Sensor Coils
Plug-in Wiring Connectors
