Franklin Electric submonitor - Programmable Options Reference

12
Default (On / Off)
Trip Point Settings Timeout Settings
Default Setting
Adjustable Range
Default Setting
Adjustable Range
General Parameters
Min
Max
Increment
Min
Max
Increment
minutes / seconds
Restart Attempts - Underload On 3 0 10* 1 Restarts Restart Attempts - All Other On 3 0 10* 1 Restarts Time Between Starts 1 0 10 1 min Power Up Delay 30 10 120 10 sec
Specifi c Parameters
Underload On 65% 30% 100% 5% of SFA 30 10 120 10 min Overload On 125% 80% 125% 5% of SFA 10 5 60 5 min Undervoltage Off 90% 80% 90% 2% of Vrated 1 1 15 1 min Overvoltage Off 110% 110% 120% 2% of Vrated 1 1 15 1 min Current Unbalance Off 5% 2% 10% 1% 10 5 60 5 min Overheated Motor On 10 5 60 5 min False Start (Chattering) On 10 0 0 0 starts in 10 sec. 1 1 15 1 min
* Unlimited restarts (
**) may also be selected.
Programmable Options
