10
Whenever a setting is changed in the menu, the change is recorded in the
event history as a Parameter Change. The parameter that was changed
is identifi ed with a parameter number per the following table, and the new
setting is recorded.
Parameter
Number
Description
0 Motor Rated Frequency
1 Motor Rated Voltage
2 Motor SFA - hundreds digit
3 Motor SFA - tens digit
4 Motor SFA - ones digit
5 Motor SFA - tenths digit
7* Trip Enable Flags
8* Auto Restart Flags
9 Number of Underload Restarts
10 Number of Other Restarts
11 Time Between Starts
12 Power-Up Time Delay
13 Underload Trip Point
14 Timeout for Underload Trip
15 Overload Trip Point
16 Timeout for Overload Trip
17 Unbalance Trip Point
18 Timeout for Unbalance Trip
19 Timeout for Overheat Trip
20 Overvoltage Trip Point
21 Timeout for Overvoltage Trip
22 Undervoltage Trip Point
23 Timeout for Undervoltage Trip
24 Number of False Starts
25 Timeout for False Start Trip
* Flags are binary format (ei. 1101001) where 1=enabled; 0=disabled.
Order of fl ags: underload, overload, unbalance, overheat, overvoltage,
undervoltage, false start.
For example, for fl ags 1101001:
Underload, overload, overheat, and false start trips are enabled.
Unbalance, overvoltage, and undervoltage trips are disabled.
Key to Parameters in Event History
