FR200F series Special Purpose Inverter
- 2 -
Chapter 1 Product Information
1.1 Nameplate Information
Figure 1-1 Nameplate Information
Model Instruction
Model numbers on nameplate consist of numbers, symbols, and letters, to express its respective
series, suitable power type, power level and other information.
FR200F-4T-7.5B
Products series Number
FR200F: Special Purpose
Inverter for Textile Machine
Input Voltage Level
2: 220V(-15%～+30%）
4: 380V(-15%～+30%）
Input Voltage Phase
S: Single Phase
T: Three Phase
Brake Unit:
Null: no built-in brake unit
B: built-in brake unit (standard
upto 30kw, optional for
37~75kw, no built-in from 90kw)
Adaptive motor power and type:
7.5G: 7.5kW(general type）
Figure 1-2 Product Model Naming Rules
