PARTS LIST
1 Main Frame 1 57 Left main frame cover 1
2 5# Allen Wrench 1 58 Right main frame cover 1
3 Wrench w/ screw driver 1 59 Back main frame cover 1
4 Magnetic ring 1 60 Spring up socket 6
5 Magnetic core 1 61 Oval spring 6
6 Single line Brown 1 62 Spring bottom socket 6
7 Single line Blue 1 63 Handlebar up cover 2
8 Single line Brown 2 64 Handlebar left side
cover
2
9 Single line Blue 1 65 Handlebar right side
cover
2
10 Earth wire 1 66 Handlebar bottom cover 2
11 Power wire S=13
、
14
、
15 1 67 Turning bushing 4
12 Base frame 1 68 Moving wheel bushing 4
13 Left upright tube 1 69 Rubber pad 4
14 Right upright tube 1 70 Left hand pulse plate 2
15 Console bracket 1 71 Right hand pulse plate 2
16 Console controller 1 72 Hand pulse sensor 2
17 Lower controller 1 73 Hand pulse buttons 4
18 DC Motor 1 74 Hand pulse button
board
2
19 Motor bracket 1 75 Incline bracket 1
20 Safety key 1 76 Incline motor 1
21 Front roller 1 77 Adjustable wheel 2
22 Rear roller 1 78 Nut M6 2
23 Running belt 1 79 Nut M8 6
24 Running board 1 80 Nut M8 4
25 Motor belt 1 81 Nut M10 6
26 Side rail 2 82 Bolt M8*15 10
27 Left end cap 1 83 Bolt M8*20 4
28 Right end cap 1 84 Bolt M8*30 1
29 Motor top cover 1 85 Bolt M8*32 4
30 Motor bottom cover 1 86 Bolt M8*40 2
31 Cylinder 1 87 Bolt M8*70 2
32 Moving wheel 2 88 Bolt M10*30 4
33 Round protect plug 2 89 Bolt M10*45 1
34 Console top cover 1 90 Bolt M10*100 1
35 Console bottom wire 1 91 Bolt M6*25 6
36 Console panel 1 92 Bolt M6*25 2
37 Power switch 1 93 Bolt M6*55 3
38 Overload protector 1 94 Bolt M8*40 1
