39 Console up wire 1 95 Bolt M5*16 6
40 Console middle wire 1 96 Bolt M5*8 15
41 Console bottom cover 1 97 Screw ST2.9*6.5 18
42 Power socket 1 98 Screw ST2.9*8 8
43 Console middle wire 6 99 Screw ST3.5*12 4
44 Cone-shaped foot pad 2 100 Screw ST4.2*12 39
45 Blue cushion 4 101 Screw ST4.2*20 2
46 Black cushion 2 102 Screw ST4.2*25 2
47 Blue cushion 2 103 Screw ST4.2*40 2
48 Oval cushion 6 104 Screw ST4.2*12 12
49 Left upright tube cover 1 105 Lock washer 3
50 Right upright tube cover 1 106 Lock washer 14
51 Acrylic board 1 107 Lock washer 2
52 Speed sensor 1 108 Washer 8
53 Speaker 2 109 Flat washer 7
54 Left speaker net 1 110 Spring washer 6
55 Right speaker net 1 111 Filter Optional 1
56 Safety key 1 112 Inductor Optional 1
113 Bolt M8*45 1
TROUBLE SHOOTING
1.There is no display on screen after the machine is connected to the power source:
a: Please check the overload button, if the overload protector button bounce, please press
this button;
b: Please make sure the power source, overload protector ,the driver and the transformer
are connected well;
c: Please make sure the wire from the driver to the computer board are connected well.
d: Check the transformer, if it is wrong, please change a new one;
2.E01 display: Failure of signal from computer board to the driver
a: Please check the wire from the drive to the computer board, if the wire is broken, please
change a new one.
b: Please check the electronic parts in computer board, if it is wrong, change a new one;
c: Change a new transformer;
3. E02 display: Anti-explosion protect or motor problem
