Need support? support.freenove.com
12
Preface
Hardware interface diagram of RPi 4B is shown below:
Hardware interface diagram of RPi 3B+/3B/2B/1B+ are shown below:
GPIO
Connector
Display
Connector
Power
Connector
HDMI
Connector
Camera
Connector
Ethernet
Connector
GPIO
Connector
Display
Connector
Power
Connector
MINI HDMI
Connector x2
Camera
Connector
Ethernet
Connector
USB
Connector x4
Audio
Connector
USB
Connector
Audio
Connector
