FREEWAY Transactive Xtra - Specifications

999075 – Rev F Page 22 of 40
5 . 2 Specifications
Ceiling Hoist Specifications
Safe Working Loads
Transactive Xtra 200KG
200KG
Transactive Xtra 270KG
270KG
Hoist Speeds
Lifting Speed 0kg
56.36 mm/s
Lifting Speed 200kg
33.56 mm/s
Lifting Speed 270kg
29.23 mm/s
Lowering Speed 0kg
55.75 mm/s
Lowering Speed 200kg
57.86 mm/s
Lowering Speed 270kg
58.87 mm/s
Battery Specification
Lead Acid Batteries – x2
24VDC (2x 12VDC) 5.0 AH
Battery Capacity – Raising/Lowering (Top 500mm of
Lift Tape) – (200kg)
60 Lifts
Battery Capacity – Raising/Lowering (Top 500mm of
Lift Tape) – (270kg)
33 Lifts
Maximum Charging Time
8.5 hrs
Raising/Lowering Duty Cycle
15% use, 85% rest (90 seconds use, 510 seconds rest)
Component Weights
Ceiling Hoist
10kg (22lbs)
Battery charger
0.8kg (1.76 lb)
Carry bar
2 kg (4.4 lb)
Handset
0.2kg (0.44 lb)
Operational Forces
Handset (Pneumatic)
3N
Emergency cord
15N
Hook locking mechanisms on lift tape
2.5N
Spring clips on carry bar
8N
Manually traversing fully loaded ceiling hoist (SWL)
50N
Manually traversing unloaded ceiling hoist (No weight)
10N
Charger Specification
Charger Type
In-Track Charging
Charger Input
100-240V AC 50/60Hz 0.7A
Charger Output
24VDC/1.0A
Motor Specification
Ceiling Hoist Motor
24VDC
Drive Motor (if applicable)
24VDC
Ceiling Hoist Protection
Ceiling Hoist Case
Flame Retardant ABS
Ceiling Hoist Case Degree of Protection
IP21
Handset Degree of Protection
IP67
Sound Level
Sound Level
54 dB
Table 5-2-1
