Footwell Lights
There are optional red lights mounted underneath the
dash on the driver’s and the passenger’s sides of the
vehicle. These lights are activated by a rocker switch
on the lower dash panel next to the climate control
switches.
Windshield Washer Reservoir
The windshield washer reservoir is located on the
left-hand side of the frontwall between the surge tank
and the hood. See Fig. 3.9.
1
2
3
f820190
01/15/97
1. Surge Tank
2. Washer Reservoir
3. Drain
Fig. 3.9, Windshield Washer Reservoir
Vehicle Access
3.7
