Service Manual STG5/7 STW5/7 form 9123659 rev. 03/2014 Page 41
EXPLODED VIEWS AND PARTLISTS
Item Part number Qt. Description
80.S 9179859S 1 Door service side, ass.
80-1 9170441 1 Hinge profile
80-2 4288321 2 Screw M5 x 16, SS socket
button head
80-3 9172080 2 Protection profile
80-4 9172054 2 Brass bearing 8 mm
80-5 9172122 4 Brass bearing 8 mm, adjusted
80-6 9174079 2 Mounting profile, hinge side
80-7 3702342 8 Flange bush, PTFE 3 mm
80-8 4311110 4 Washer
80-9 0144359 4 Nut, self locking M5
80-10 4288320 2 Screw M5x45 SS
80-11 9174680 2 Washer
80-12 9070141 12 Magnet block
80-13 9174083 1 Fastening, door handle
80-14 9170464 1 Profile, magnet
80-15 9174132 1 Door handle
80-16 9172300 2 Spacing pin
80-17 9171014 2 Plug, door handle
81.C 9179860S 1 Door customer side, ass.
81-1 9170441 1 Hinge profile
81-2 4288321 2 Screw M5 x 16, SS socket but-
ton head
81-3 9172080 2 Protection profile
81-4 9172054 2 Brass bearing 8 mm
81-5 9172122 2 Brass bearing 8 mm, adjusted
81-6 9174079 1 Mounting profile, hinge side
81-7 3702342 8 Flange bush, PTFE 3 mm
81-8 4311110 2 Washer
81-9 0144359 2 Nut, self locking M5
81-12 9070141 12 Magnet block
81-13 9174083 1 Fastening, door handle
81-14 9170464 1 Profile, magnet
81-18 4288321 2
Screw M5 x 16, SS socket
button head
81-19 0144359 2 Nut, self locking M5
81-20 9174680 2 Washer
Item Part number Qt. Description
82 9179855S 2 Door inside, ass.
82-1 9170442 2 Hinge profile
82-2 0211520 4 Bolt M5 x 12 ss hexagon head
82-3 3702341 16 Flange bush, PTFE 2 mm
82-4 9174080 2 Cover profile, inner glass
82-5 4285408 8 Nut, M5
82-6 9174081 2 Holder, magnet
82-7 9070141 14 Magnet block
82-8 9174084 2 Profile
82-9 9172081 4 Spacing pin
83 9170427 1 Hinge, left
84 9174026 1 Hinge, right
To Next Page
