Service Manual STG5/7 STW5/7 form 9123659 rev. 03/2014
Page 6
GENERAL TECHNICAL DATA
This manual covers the STG series rotisserie ovens and the STW series warmers. Ovens and
warming cabinets come in two sizes. Ovens and cabinets will also be delivered in stacked
versions.
• STG5–Ovenwithvespits(15to20chickens)
• STG7–Ovenwithsevenspits(28to35chickens)
• STW5Warmingcabinet.
• STW7Warmingcabinet.
Alloftheinformation,illustrationsandspecicationscontainedinthismanualarebasedon
thelatestproductinformationavailableatthetimeofprinting.
Type STG 5 STGW 5 STG 7 STGW 7 STW 5 STW 7
Power(W) 6500 9300 10200 13700 2800 3500
Fusesneededwithpowerconnec-
tion400V,3N~50…60Hz
(3phaseswithzero)
3x16A 3x16A 3x16A 3x32A - -
Fusesneededwithpowerconnec-
tion200or230V,3~50…60Hz
(3phaseswithoutzero)
3x16A 3x32A 3x32A 3x35A - -
Fusesneededwithpowerconnec-
tion230V,1N~50…60Hz
(1phasewithzero)
- - - - 1x16A 1x16A
Standardplugfromfactory5-pole
AccIEC309andCEE-form
16A
3P+N+E
16A
3P+N+E
16A
3P+N+E
32A
3P+N+E
- -
Standardplugfromfactorysingle
pole
_ _ _ _ 2-poleearthed
plug16A
2-poleearthed
plug16A
Netweight(kg) 122 222 181 331 100 150
Grossweight(kg) 159 260 217 382 122 165
Height(mm) 870 1750 1025 2060 870 1025
Width(mm) 825 825 985 985 825 985
Depth(mm) 650 650 850 850 650 850
• Standardsetoftools.
• Metricwrenches,socketsandhexsocketkeywrenches.
• Multi-meterandACcurrentclampmeter.
• Temperaturetester.
• Insulationvaluetester(Megger).
• FieldServiceGroundingKit.
