Fri-Jado STG - Page 45

Service Manual STG5/7 STW5/7 form 9123659 rev. 03/2014 Page 45
EXPLODED VIEWS AND PARTLISTS
Item Part number Qty. Description
40 9170055 1 Rotorset ass., stainless
steel
40-1 9070272 1 Rotor shaft, stainless steel
40-2 9174351 2 Rotor disc 3 mm,
stainless steel
40-3 4288231 12 Tensilock bolt M5x10,
stainless steel
40-4 9172169 14 Support pin, stainless steel
40-5 0142056 14 Spring washer M8, support
pin, stainless steel
40-6 4312271 14 Nut M8, support pin,
stainless steel
41 9172063 1 Steel bearing, 14 mm
42 9172153 7 Meatfork 8 mm SS
42 9172242 7 Meatfork 8 mm, coated
43 9112210 2 Mounting plate, lamp
holder
44 9040023 2 Heating element 230 V,
2100 W
45 9044653 1 Heating element 230 V,
3100 W
46 9110023 4 Lamp holder, cap +
housing
47 9056082 2 Quartz light, 1000 W
48 9116662 2 Protection, lamp
49 9110048 2 Blower
49-1 9110153 2 Fanblade
49-2 9073150 2 Wingnut, left hand
threaded
50 9173051 1 Electric panel, ass.
50-1 0166555 1 Earth symbol
50-2 8033659 1 Connecting block, 9-pol.
50-3 9044564 1 Connecting block, 1,2,3
50-4 9044572 1 Connecting block, 4,5,6
50-5 9070531 1 Safety thermostat
50-250 °C
50-6 9070840 2 Grommet
50-7 3500069 1 Contactor
50-8 9077088 1 Rail
50-9 9077101 1 Capacitor 2.5mF
50-9A 9077102 1
Capacitor 3 uF (till serial
nr. 100061450)
50-10 9110030 2 Capacitor 1,5 mF
50-11 9174106 1 Electric panel
50-12 9171140 1 Main switch
50-12A 9172328 1 Main switch (till serial
number 100050804)
Item Part number Qty. Description
51 9110025 1 Fuse housing
52 9110026 2 Fuse holder
53 9171120 2 Fuse 5x20, ceramic T10A
54 9174161 1 Protection support
55 9173004S 1 Gearmotor, complete
with drive arm and capaci-
tor 2.5 uF
56 9172078 1 Fanblade Ø 150 mm, gear-
motor
57 9110797 1 Sealring, drive bearing
58 9073131 1 Sealing ring
59 9172045 1 Keypad + backplate
60 9171018 3 Plug
61 9110242 1 Display
62 9044140 1 Sensor cable
63 9070094 1 Temperature sensor
64 9151010 1 Connecting block
65 9172040 2 Name plate Fri-jado,
foil + backplate
66 9173017 1 Main power knob
assembly
66-1 9172049 1 Back plate, main switch
0-1
66-2 9172021 1 Contron knob, grey
66-3 9172037 1 Back plate, main switch
0-1
66-4 9172052 1 Locking ring
66-5 9110802 1 Seal ring
67 9110276 1 Power and I/O board
68 9172113 1 Flatcable, 34-pol. (P)
69 9070028 1 Connecting cable with
plug 16A
