Service Manual STG5/7 STW5/7 form 9123659 rev. 03/2014 Page 53
EXPLODED VIEWS AND PARTLISTS
Item Part num-
ber
Qty. Description
1 ...... 1 Frame
2 9170419 1 Side panel, left
3 9170479 1 Side panel, right
4 9110810 1 Indication plate
5 4288322 8 Screw M5 x 10, SS socket button head
6 9174045 1 Cap, top
7 9170421 1 Side panel, top
8 9174046 1 Reinforcement, side plate, right
9 9174005 1 Cover, removable
10 9174048 1 Cover plate, machine components
11 9172053 1 Nut
12 9170462 1 Operation panel
13 9174031 1 Panel, customer side
14 9174053 5 Runner
14A 9170411 1 Runner rack (till serial nr. 10006422)
15 9174052 1 Profile for bottom plate
16 9171020 12 Spacing pin
17 9040748 3 Display rack
18 9174044 1 Inner bottom
19 9170451 1 Drawer
20 9171008 1 Drain-tap with handle
21 9170412 1 Cover plate, blower
22 9174140 1 Spark catcher
23 9174034 1 Mounting plate
24 9222076 1 Strain relief M20
25 9222077 1 Connector M20
26 9172116 2 Sealing profile, Silicon L= 71 cm
27 9172066 2 Swivel castor with brake
28 9172125 2 Rigid castor
To Next Page
