38 PB
INSTALLATION
Leak Check, Evacuation, and Charging (Triple Evacuation)
WAIT
EVACUATE
BREAK VACUUM WITH DRY NITROGEN
CHARGE SYSTEM
EVACUATE
WAIT
EVACUATE
CHECK FOR TIGHT, DRY SYSTEM
(IF IT HOLDS A VACUUM)
BREAK VACUUM WITH DRY NITROGEN
Capacity
(Btu/h)
Pipe Size Standard
Length (ft)
Max.
Elevation
B (ft)
Max. Length
A (ft)
Additional
Refrigerant
(oz/ft)
LIQUID GAS
9k-12 1/4"(Ø6.35) 3/8"(Ø9.52) 25 33 50 .22
18k 1/4"(Ø6.35) 1/2"(Ø12.7) 25 33 66 .22
24k-36k 3/8"(Ø9.52) 5/8"(Ø15.88) 25 33 66 .32
Fig. 437
Fig. 436
