Friedrich FPHSW09A1B Service Manual

84 PB
WIRING DIAGRAMS
Wiring Diagram Lookup Table
Model Number Indoor Unit Indoor Unit Wiring
Diagram
Outdoor Unit Outdoor Unit
Wiring Diagram
Voltage BTU
FPHW091/A FPHSW09A1A,
FPHSW09A1B
1912241 FPHSR09A1A 1912204 115 9k
FPHW093/A FPHFW09A3A,
FPHFW09A3B
1854605
1912241
1907790
FPHSR09A3A 1854707 208/230 9k
FRHW093/A FRHSW09A3A,
FRHSW09A3B
1854605
1912241
1907790
FRHSR09A3A 1854707 208/230 9k
FPHW121/A FPHSW12A1A,
FPHSW12A1B
1912241 FPHSR12A1A 1912204 115 12k
FPHW123/A FPHFW12A3A,
FPHFW12A3B
1854605 FPHSR12A3A 1854707 208/230 12k
FRHW123/A FRHSW12A3A,
FRHSW12A3B
1854605 FRHSR12A3A 1854707 208/230 12k
FPHW183/A FPHFW18A3A,
FPHFW18A3B
1854605
1854698
FPHSR18A3A 1854707 208/230 18k
FPHW243/A FPHFW24A3A,
FPHFW24A3B
1854698 FPHSR24A3A 1854707 208/230 24k
FPHW363/A FPHSW36A3A,
FPHSW36A3B,
FPHSW36A3C
1852066 FPHSR36A3A,
FPHSR36A3B
1854707 208/230 36k
