213 PB
FIGURE 902
ITEM PART
NUMBER
PART DESCRIPTION USED ON MODEL QTY
1 67400388 fan guard FPHMR24A3A 1
2 67400336 front panel FPHMR24A3A 1
3 67400337 Left guard filter FPHMR24A3A 1
4 67400998 mounting plate FPHMR24A3A 1
5 67400999 Welding hex nuts FPHMR24A3A 1
6 67400340 propeller fan FPHMR24A3A 1
7 67400341 FAN MOTOR FPHMR24A3A 1
8 67400342 motor bracket FPHMR24A3A 1
9 67400343 upper cover FPHMR24A3A 1
10 67400344 back guard filter FPHMR24A3A 1
11 67400345 side panel FPHMR24A3A 1
12 67400268 PFC inductance FPHMR24A3A 1
13 67400919 separate plate assy FPHMR24A3A 1
14 67400347 valve cover FPHMR24A3A 1
15 67400211 sensor mounting plate FPHMR24A3A 1
16 67401007 handle FPHMR24A3A 1
17 67400921 baffle FPHMR24A3A 1
18 67400922 fixed board FPHMR24A3A 1
19 67400351 Tube electric heater FPHMR24A3A 1
20 67400352 condenser ASS'Y FPHMR24A3A 1
21 67401000 pipe ASS'Y FPHMR24A3A 1
22 67400924 outlet tube ASS'Y FPHMR24A3A 1
23 67400355 electric expansion valve ASS'Y FPHMR24A3A 1
24 67400356 Electromagnetic coil A FPHMR24A3A 1
25 67400357 Electromagnetic coil B FPHMR24A3A 1
26 67400358 Electromagnetic coil C FPHMR24A3A 1
27 67400359 1/4 stop valveASS'Y FPHMR24A3A 1
28 67400360 3/8 stop valveASS'Y FPHMR24A3A 1
29 67400925 base FPHMR24A3A 1
30 67400945 mounting plate FPHMR24A3A 1
31 67400363 compressor FPHMR24A3A 1
32 67401001 noise‑insulation cotton FPHMR24A3A 1
33 67401002 noise‑insulation cotton FPHMR24A3A 1
34 67400366 Crankcase Heater FPHMR24A3A 1
35 67401003 noise‑insulation cotton FPHMR24A3A 1
36 67401004 noise‑insulation cotton FPHMR24A3A 1
37 67400931 suction tube assy FPHMR24A3A 1
PARTS CATALOG
24K Outdoor Condensor
To Next Page
