227 PB

PARTS CATALOG

24K INDOOR CASSETTE

Figure 906

ITEM PART

NUMBER

PART DESCRIPTION USED ON MODEL QTY

1 67400872 Base FPHC24A3A 1

2 67400984 Air Duct Plate FPHC24A3A 1

3 67400438 Fan Motor FPHC24A3A 1

4 67400985 Side Panel FPHC24A3A 1

5 67400986 Fan Snail Shell FPHC24A3A 1

6 67400439 Pump Motor FPHC24A3A 1

7 67400987 Cover FPHC24A3A 1

8 67400440 Drainage Hose FPHC24A3A 1

9 67400441 Centrifugal Fan FPHC24A3A 1

10 67400442 Water Collecting Box FPHC24A3A 1

11 67400988 Mounting Plate FPHC24A3A 1

12 67400865 Elec Joint Box FPHC24A3A 1

13 67400989 Elec Joint Box Cover FPHC24A3A 1

14 67400365 Terminal Panel FPHC24A3A 1

15 67400443 Main Control Board FPHC24A3A 1

16 67400990 Cross Recessed Cheese Head

Screws

FPHC24A3A 1

17 67400444 Coil Temperature Sensor FPHC24A3A 1

18 67400991 Mounting Plate FPHC24A3A 1

19 67400445 Evaporator FPHC24A3A 1

20 67400992 Side Panel FPHC24A3A 1

21 67400993 Connecting Plate FPHC24A3A 1

22 67400994 Side Panel FPHC24A3A 1

23 67400446 Ambient Temperature Sensor FPHC24A3A 1

24 67400447 Water Level Switch FPHC24A3A 1

‑ITEMS ARE NON‑ ILLUSTRATED

*ITEMS ARE NON‑STOCKED, WILL NORMALLY REQUIRE 2‑3 WEEKS LEAD TIME
