231 PB
PARTS CATALOG
9K, 12K DUCTED INDOOR
Figure 907
ITEM PART NUMBER PART DESCRIPTION USED ON MODEL QTY
1 67400885 Base Plate FPHD09A3A, FPHD12A3A 1
2 67400886 Bottom Plate FPHD09A3A, FPHD12A3A 1
3 67400887 Water Drain FPHD09A3A, FPHD12A3A 1
4 67400409 Evaporator FPHD09A3A, FPHD12A3A 1
5 67400902 Supporting FPHD09A3A, FPHD12A3A 1
6 67400889 Electric Box Cover FPHD09A3A, FPHD12A3A 1
7 67400904 Seal Plate FPHD09A3A, FPHD12A3A 1
8 67400891 Rght Side Board FPHD09A3A, FPHD12A3A 1
9 67400414 Water Position Switch FPHD09A3A, FPHD12A3A 1
10 67400415 Temperature Sensor FPHD09A3A, FPHD12A3A 1
11 67400416 Temperature Sensor FPHD09A3A, FPHD12A3A 1
12 67400892 Fan Board FPHD09A3A, FPHD12A3A 1
13 67400907 Motor Supporter FPHD09A3A, FPHD12A3A 1
14 67400894 Fan Snail Shell FPHD09A3A, FPHD12A3A 1
15 67400417 Fan FPHD09A3A, FPHD12A3A 1
16 67400911 Hooking FPHD09A3A, FPHD12A3A 1
17 67400896 Connecting Rod FPHD09A3A, FPHD12A3A 1
18 67400897 Hooking FPHD09A3A, FPHD12A3A 1
19 67400411 DC Motor FPHD09A3A, FPHD12A3A 1
20 67400915 Elec Joint Box FPHD09A3A, FPHD12A3A 1
21 67400420 Electric Box FPHD09A3A, FPHD12A3A 1
22 67400995 PCB FPHD09A3A 1
22a 67400421 PCB FPHD12A3A 1
‑ITEMS ARE NON‑ ILLUSTRATED
*ITEMS ARE NON‑STOCKED, WILL NORMALLY REQUIRE 2‑3 WEEKS LEAD TIME
To Next Page
