Friedrich MRM09Y1J Service & Parts Manual

11 PB
SPECIFICATIONS
Model of Outdoor Unit
UNIT OF
MEASURE
MWM09Y1J
MRM09Y1J
MWM12Y1J
MRM12Y1J
MWM18Y3J
MRM18Y3J
MWM24Y3J
MRM24Y3J
MWM36Y3J
MRM36Y3J
OUT-
DOOR
UNIT
Product Code CB146W0431_L13396 CB146W0451_L13396 CB146W17401_L13396 CB146W01401_L13396 CB146W10800_L13396
Compressor Manufacturer/
Trademark
ZHUHAI LANDA
COMPRESSOR
ZHUHAI LANDA
COMPRESSOR
MITSUBISHI ELECTRIC
(GUANG ZHOU)
COMPRESSOR CO. LTD
China Resources
(Shenyang) Sanyo CO., LTD
MITSUBISHI ELECTRIC
(GUANG ZHOU)
COMPRESSOR CO. LTD
Compressor Model QXA-A091ZE190 QXA-A091ZE190 SNB130FGYMC C-6RZ146H1A TNB306FPGMC
Compressor Oil FVC68D FVC68D FV50S FV50S FV50S
Compressor Type Rotary Rotary Rotary Rotary Rotary
Compressor L.R.A. / / 10.86 12.5 67.00
Compressor RLA A 6 6 1245 1630 17.50
Compressor Power Input W 980 980 1245 1630 3010
Overload Protector Model 1NT11L-6233 1NT11L-6233 11711/-6578 11711/-3979 CS-7C-1595
Throttling Method Capillary Capillary Capillary Electron Expansion Valve Electron Expansion Valve
Operation temp ºF 61~86 61~86 61-86 61-86 61~86
Outdoor Min-Max Temp
(cooling)
ºF 64~113 64~113 5-115 5-115 0~109
Outdoor Min-Max Temp
(heating)
ºF 5~75 5~75 5-75 5-75 -4-75
Condenser Form ºF
Aluminum Fin-copper
Tube
Aluminum Fin-copper
Tube
Aluminum Fin-copper
Tube
Aluminum Fin-copper
Tube
Aluminum Fin-copper
Tube
Pipe Diameter inch 1/4 1/4 1/4 1/4 3/8
Rows-n Gap 2 1/8 2 1/8 2 1/8 2 1/8 2-1/16
Coil Length (LXDXW) 29 8/11X1X19 8/17 29 8/11X1X19 8/17 32 3/5X1 1/2X26 32 4/7X1 1/2X26 37X1 3/4X30
Fan Motor Speed rpm 900 900 690 690 890
Output of Fan Motor W 30 30 60 60 170
Fan Motor RLA A 0.17 0.17 0.62 0.62 0.73
Fan Motor Capacitor μF / / 3.5 3.5 /
Air Flow Volume of Outdoor
Unit
CFM 1059 1059 1883 1883 2589
Fan Type Axial-ow Axial-ow Axial-ow Axial-ow Axial-ow
Fan Diameter inch 15 10/13 15 10/13 20 1/2 20 1/2 21 21/32
Defrosting Method Auto Defrosting Auto Defrosting Auto Defrosting Auto Defrosting Auto Defrosting
Climate Type T1 T1 T1 T1 T1
Moisture Protection IP24 IP24 IP24 IP24 IP24
Design Pressure(High) PSIG 550 550 550 550 550
Design Pressure(Low) PSIG 240 240 240 240 240
Sound Pressure Level
(H/M/L)
dB (A) 53 55 56 53 65/-/-
Sound Power Level (H/M/L) dB (A) 63 65 66 63 75/-/-
Dimension (WXHXD) inch 33 2/5X21 1/4X12 3/5 33 2/5X21 1/4X12 3/5 38;27 5/9;15 3/5 38;27 5/9;15 3/5 39 1/2;31 7/64;16 13/16
Dimension of Carton Box
(LXWXH)
inch 34 4/7X14 1/6X22 5/6 34 4/7X14 1/6X22 5/6 40 2/5;18;29 40 2/5;18;29 42 1/2;19;33
Dimension of Package
(LXWXH)
inch 34 2/3X14 2/7X23 3/7 34 2/3X14 2/7X23 3/7 40 1/2;18 1/32;29 1/2 40 1/2;18 1/32;29 1/2 42 21/32;19 13/64;33 21/32
Net Weight lb 68 68 106 115 161
Gross Weight lb 77 77 117 126 172
Refrigerant R-410A R-410A R-410A R-410A R410A
Refrigerant Charge oz 35.28 35.28 45.86 54.67 91.71
Connec-
tion
Pipe
Length ft 24.6 24.6 24.6 24.6 24.6
Gas Additional Charge oz/ft 0.21 0.21 0.2 0.2 0.2
Outer Diameter Liquid Pipe inch 1/4 1/4 1/4 1/4 1/4
Outer Diameter Gas Pipe inch 3/8 3/8 1/2 1/2 5/8
Max Distance Height ft 32.8 32.8 32.8 32.8 32.8
Max Distance Length ft 49.2 49.2 82.0 82.0 98.2
Note: The connection pipe aplies metric diameter.
Figure 202
Product Specications

Friedrich MRM09Y1J Specifications
