Friedrich MRM09Y1J Service & Parts Manual

19 PB
SPECIFICATIONS
Figure 216
24K Cooling Capacity Charts
DB (F°) TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
14 10.48 8.22 0.69 11.48 9.01 0.71 12.13 9.51 0.73 12.95 10.16 0.75 13.69 10.74 0.78 14.24 11.17 0.81 15.43 12.1 0.83
17 10.57 8.29 0.69 11.78 9.24 0.71 12.44 9.75 0.73 13.28 10.42 0.76 14.21 11.15 0.78 14.8 11.61 0.81 15.82 12.41 0.83
23 11.71 9.18 0.69 12.58 9.87 0.71 13.46 10.56 0.73 14.33 11.24 0.75 15.42 12.09 0.77 16.09 12.62 0.8 16.96 13.3 0.83
59 14.2 11.13 0.79 15.26 11.97 0.82 16.32 12.8 0.84 17.38 13.63 0.86 17.87 14.01 0.89 19.51 15.3 0.93 20.57 16.14 0.96
70 16.2 12.71 1.16 17.28 13.55 1.2 18
.36 14.4 1.24 19.08 14.96 1.27 19.62 15.39 1.31 21.06 16.52 1.37 22.5 17.65 1.4
75 15.99 12.54 1.19 17.08 13.39 1.23 18.16 14.25 1.27 18.9 14.82 1.31 19.44 15.25 1.35 20.79 16.31 1.4 22.32 17.5 1.45
80 15.58
12.22 1.25 16.66 13.06 1.29 17.74 13.91 1.33 18.54 14.54 1.37 19.26 15.11 1.41 20.52 16.09 1.46 21.96 17.22 1.51
85 15.16 11.89 1.33 16.24 12.73 1.38 17.32 13.58 1.42 18.18 14.26 1.46 18.9 14.82 1.51 20.25 15.88 1.57 21.63 16.96 1.61
90 14.74 11.57 1.39 15.82 12.41 1.44 16.9 13.25 1.48 17.82 13.98 1.52 18.54 14.54 1.57 19.98 15.67 1.64 21.2 16.63 1.68
95
14.3 11.21 1.44 15.37 12.05 1.48 16.44 12.89 1.52 17.51 13.74 1.57
18 14.12 1.62
19.65 15.41 1.68 20.72 16.25 1.73
100 13.92 10.92 1.46 14.99 11.76 1.5 16.06 12.6 1.55 17.14 13.44 1.6 17.77 13.94 1.65 19.28 15.12 1.71 20.35 15.96 1.77
105 13.55 10.62 1.48 14.62 11.47 1.53 15.69 12.31 1.58 16.76 13.15 1.63 17.53 13.75 1.67 18.9 14.82 1.74 19.97 15.66 1.79
110 13.18 10.33 1.5 14.24 11.17 1.54 15.32 12.01 1.59 16.39 12.85 1.64 17.16 13.46 1.7 18.53 14.53 1.76 19.6 15.37 1.81
115 12.8 10.04 1.51 13.87 10.88 1.56 14.94 11.72 1.61 16.01 12.56 1.66 16.79 13.16 1.71 18.16 14.24 1.7
8 19.22 15.08 1.83
118 12.42 9.74 1.53 13.5 10.59 1.58 14.4 11.29 1.63 15.48 12.14 1.67 16.2 12.71 1.73 17.55 13.77 1.79 18.54 14.54 1.85
Outdoor Air
Temp.
64 / 53 68 / 57 72 / 61 77 / 64
80 / 67
86 / 72
MM18YJ Indoor Air Temperature :DB /WB (F°)
90 / 75
Figure 215
18K Cooling Capacity Charts
DB TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
14 12.81 10.04 0.93 14.04 11.01 0.96 14.83 11.62 0.99 15.83 12.42 1.02 16.73 13.13 1.06 17.41 13.65 1.1 18.86 14.79 1.13
17 12.92 10.13 0.93 14.4 11.29 0.96 15.2 11.92 0.99 16.24 12.74 1.03 17.37 13.62 1.06 18.08 14.19 1.1 19.34 15.17 1.13
23 14.31 11.22 0.93 15.38 12.06 0.96 16.45 12.9 0.99 17.52 13.74 1.02 18.85 14.78 1.05 19.66 15.42 1.09 20.73 16.26 1.12
59 17.35 13.61 1.07 18.65 14.63 1.11 19.95 15.64 1.14 21.24 16.66 1.17 21.85 17.13 1.21 23.85 18.7 1.26 25.15 19.72 1.3
70 19.8 15.53 1.58 21.12 16.56 1.63 22
.44 17.6 1.68 23.32 18.29 1.73 23.98 18.81 1.78 25.74 20.19 1.86 27.5 21.57 1.91
75 19.54 15.33 1.62 20.87 16.37 1.67 22.2 17.41 1.72 23.1 18.12 1.78 23.76 18.64 1.83 25.41 19.93 1.91 27.28 21.39 1.97
80 19.04 14.93 1.69 20.36 15.96 1.75 21.68 17 1.8 22.66 17.78 1.86 23.54 18.47 1.91 25.08 19.67 1.99 26.84 21.05 2.05
85 18.53 14.53 1.81 19.84 15.56 1.87 21.16 16.6 1.93 22.22 17.43 1.99 23.1 18.12 2.05 24.75 19.41 2.13 26.44 20.73 2.19
90 18.02 14.14 1.89 19.34 15.17 1.95 20.65 16.19 2.01 21.78 17.08 2.07 22.66 17.78 2.13 24.42 19.15 2.22 25.91 20.32 2.29
95
17.48 13.7 1.95 18.78 14.73 2.01 20.09 15.75 2.07 21.4 16.79 2.13
22 17.26 2.2
24.02 18.84 2.29 25.32 19.86 2.35
100 17.01 13.35 1.98 18.33 14.37 2.04 19.63 15.4 2.1 20.94 16.42 2.17 21.71 17.03 2.24 23.56 18.48 2.32 24.87 19.51 2.4
105 16.56 12.98 2.01 17.87 14.02 2.08 19.18 15.04 2.14 20.48 16.07 2.21 21.43 16.81 2.27 23.1 18.12 2.36 24.41 19.14 2.43
110 16.1 12.63 2.04 17.41 13.65 2.1 18.72 14.68 2.16 20.03 15.71 2.23 20.97 16.45 2.3 22.65 17.76 2.39 23.95 18.79 2.46
115 15.64 12.27 2.05 16.95 13.3 2.12 18.26 14.32 2.19 19.57 15.35 2.25 20.52 16.09 2.32 22.19 17.4 2.41 23.
5 18.43 2.49
118 15.18 11.91 2.08 16.5 12.94 2.14 17.6 13.8 2.21 18.92 14.84 2.27 19.8 15.53 2.35 21.45 16.82 2.43 22.66 17.78 2.51
Outdoor Air
Temp.
64 / 53 68 / 57 72 / 61 77 / 64
80 / 67
86 / 72 90 / 75
MM24YJ Indoor Air Temperature :DB /WB (F°)
Symbol
DB : Dry Bulb Temperature [ °F}
WB :Wet Bulb Temperature [ °F}
TC: Total Capacity [kBtu/h]
SHC: Sensible Heating Capacity [kBtu/h]
PI: Power Input [kW]
(Comp + indoor fan motor +outdoor fan motor)
Notes
1. All capacities are net, evaporator fan motor heat is deducted.
2. Indicates reference data. When operating at this temperature, these values can be different by operation.
3. Direct interpolation is permissible. Do not extrapolate.
4. Capacities are based on the following conditions:
Interconnecting Piping length 7.5m (24.6 ft) - Level difference of 0PSI
Indoor Air Temperature: 80°F (26.7°C) DB / 67°F (19.4°C) WB
Outdoor Air Temperature: 95°F (35.0°C) DB 75°F (23.9°C) WB
