Friedrich MRM09Y1J Service & Parts Manual

10 PB
SPECIFICATIONS
UNIT OF
MEASURE
MWM09Y1J
MRM09Y1J
MWM12Y1J
MRM12Y1J
MWM18Y3J
MRM18Y3J
MWM24Y3J
MRM24Y3J
MWM36Y3J
MRM36Y3J
Product Code CB146035101_L13396 CB146035001_L13396 CB146032301B/13396 CB146032101B/13396 CB471000100_L13396
Power
Supply
Rated Voltage V~ 115 115 208/230 208/230 208/230
Rated Frequency Hz 60 60 60 60 60
Phases 1 1 1 1 1
Power Supply Mode Outdoor Outdoor Outdoor Outdoor Outdoor
Rated Cooling Capacity
(Min~Max)
Btu/h 9000(3500~11000) 11800(3300~12500) 18000(4500~21000) 22000(6400~24000) 33600(7404~35997)
Rated Heating Capacity
(Min~Max)
Btu/h 9800(2500~11000) 13000(3400~13500) 19200(4000~23000) 24200(4100~26600) 34600(14979~35997)
Cooling Power Input
(Min~Max)
W 750(220~1100) 1260(260~1340) 1700(200~2600) 2200(300~2550) 4100(450~4300)
Heating Power Input
(Min~Max)
W 830(230~1230) 1320(250~1360) 2400(300~2600) 2800(320~2800) 3800(560~4300)
Cooling Power Current A 9 15 8.3/7.5 11.5/10.5 17
Heating Power Current A 9.5 15.5 11.77/10.65 13.0/12.8 16.5
Rated Input W 1230 1360 2600 2800 4300
Rated Current A 17.0 18.2 11.8/10.9 13.0/12.8 20
Air Flow Volume(SH/H/M/L/
SL)
CFM 330/277/224/188/- 341/288/235/200/- 471/400/330/371/- 589/441/306/206/- 736/647/530/412
Dehumidifying Volume Pint/h 1.69 2.96 3.80 5.00 7.4
EER
(Btu/h)/W 12 9.4 10.59 10.0 8.20
COP (Btu/h)/W 12 9.8 8.0 9.5 9.11
SEER (Btu/h)/W 16 16 16 16 18.00
HSPF (Btu/h)/W 8.6 8.6 8.5 9.5 9.00
Typical Application Area sq ft 144-215 191-287 207-384 353-502 501-837
INDOOR
UNIT
Model of indoor unit MWM09Y1J MWM12Y1J MWM18Y3J MWM24Y3J MWM36Y3J
Product Code CB146N35100_L13396 CB146N35000_L13396 CB146N32300_L13396 CB146N32101_L13396 CB471N00100_L13396
Fan Type Cross-ow Cross-ow Cross-ow Cross-ow Cross-ow
Diameter
Length(DXL)
inch
3 5/8 X 23 3/8 rounded to
the nearest 1/8
3 5/8 X 23 3/8 rounded to
the nearest 1/8
3 7/8 X 25 5/8 rounded to
the nearest 1/8
3 7/8 X 30 1/8 rounded to
the nearest 1/8
4 1/4 X 20 9/16 rounded to
the nearest 1/8
Fan Motor Cooling
Speed (SH/H/M/L/
SL)
r/min 1300/1100/900/700/- 1350/1150/950/750/- 1400/1150/1000/850/- 1350/1150/1000/850/- 1400/1250/1000/800
Fan Motor Heating
Speed (SH/H/M/L/
SL)
r/min 1300/1150/980/820/- 1350/1200/1000/850/- 1450/1250/1100/950/- 1350/1150/1000/900/- 1400/1250/1050/850
Output of Fan Motor W 15 15 20 35 70
Fan Motor RLA A 0.38 0.38 0.32 0.45 0.4
Fan Motor Capacitor μF 4 4 1.5 2.5 /
Evaporator Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube Aluminum Fin-copper Tube Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter inch 1/4 1/4 1/4 1/4 9/32
Row-n Gap inch 1/4 1/4 1/4 1/4 2-1/16
Coil Length (LXDXW) inch 24X17/18X11 4/7 24X17/18X11 4/7 25 7/8 X 1 X 12 30 1/8 X 1 X 13 1/2 42 9/32 X 1 X 15
Swing Motor Model MP24BA MP24BA MP28VB MP35XX MP24BA
Output of Swing
Motor
W 2.4 2.4 2 2.5 1.5
Fuse A 3.15 3.15 3.15 3.15 5
Sound Pressure
Level (SH/H/M/L/SL)
dB (A) 41/37/35/32/- 43/39/35/32/- 48/43/38/34/- 49/43/39/34/- 54/49/44/37
Sound Power Level
(SH/H/M/L/SL)
dB (A) 51/47/45/42/- 53/49/45/42/- 58/53/48/44/- 59/53/49/44/- 64/59/54/47
Dimension (WXHXD) inch 30 1/3X11 1/7X8 30 1/3X11 1/7X8 34 1/7;12;8 1/2 39 5/7;12 5/9;8 2/3 53 9/64;12 53/64;10
Dimension of Carton
Box (LXWXH)
inch 33 2/9X13 1/2X10 2/7 33 2/9X13 1/2X10 2/7 37 1/5;14 9/10;11 3/5 42 1/4;15 5/9;12 1/3 56 19/32;16 1/2;13 1/2
Dimension of Pack-
age (LXWXH)
inch 33 1/3X13 4/7X10 6/7 33 1/3X13 4/7X10 6/7 37 1/3;15;12 1/5 42 1/3;15 2/3;13 56 3/4;16 9/16;14
Net Weight lb 19 19 26 33 19
Gross Weight lb 23 23 33 39 23.5
Figure 201
Product Specications

Friedrich MRM09Y1J Specifications
