Friedrich MRM09Y1J Service & Parts Manual

18 PB
SPECIFICATIONS
Figure 215
9K Cooling Capacity Charts
DB TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
14 5.63 4.59 0.25 6.11 5.03 0.26 6.56 5.32 0.27 7.01 5.68 0.28 7.52 6.00 0.29 7.68 6.24 0.30 7.94 6.76 0.30
17 5.72 4.64 0.26 6.41 5.17 0.27 6.75 5.46 0.28 7.16 5.83 0.29 7.80 6.24 0.30 8.12 6.50 0.31 8.13 6.95 0.31
23 6.30 5.04 0.28 6.77 5.42 0.30 7.25 5.80 0.30 7.71 6.17 0.31 8.41 6.64 0.32 8.64 6.93 0.33 9.23 7.30 0.34
59 7.63 6.10 0.35 8.20 6.56 0.38 8.77 7.01 0.39 9.43 7.47 0.40 9.60 7.68 0.41 10.48 8.38 0.43 11.05 8.84 0.42
70 9.78 7.40 0.
50 10.39 7.90 0.52 11.24 8.39 0.54 11.48 8.72 0.55 11.80 8.73 0.57 12.67 9.63 0.60 13.53 10.28 0.61
75 9.46 7.19 0.53 10.10 7.68 0.55 10.74 8.16 0.56 11.18 8.50 0.58 11.50 8.51 0.60 12.31 9.35 0.62 13.20 10.03 0.64
80 9.06 6.61 0.57 9.69 7.07 0.59 10.23 7.53 0.60 10.78 7.87 0.62 11.20 8.06 0.64 11.93 8.71 0.66 12.77 9.32 0.69
85 8.18 5.92 0.60 8.65 6.32 0.62 9.32 6.74 0.64 9.69 7.07 0.66 10.07 7.25 0.68 10.79 7.88 0.71 11.52 8.41 0.74
90 7.12 5.60 0.79 8.70 6.01 0.82 9.30 6.42 0.84 9.80 6.76 0.86 10.20 7.04 0.89 10.98 7.
58 0.93 11.77 8.05 0.95
95
7.94 5.48 0.85 8.54 5.89 0.88 9.13 6.30 0.90 9.73 6.71 0.93
10.11 6.90 0.96
10.92 7.53 1.00 11.51 7.94 1.03
100 7.54 5.13 0.88 8.01 5.53 0.92 8.59 5.92 0.95 9.26 6.32 0.98 9.50 6.56 1.01 10.31 7.11 1.05 10.77 7.51 1.08
105 7.19 4.96 0.93 7.85 5.35 0.96 8.23 5.74 0.99 8.89 6.14 1.02 9.30 6.42 1.05 10.03 6.92 1.09 10.59 7.31 1.13
110 6.89 4.82 1.05 7.55 5.21 1.07 8.12 5.61 1.10 8.76 6.00 1.14 9.10 6.28 1.18 9.82 6.78 1.22 10.35 7.17 1.26
115 5.05 3.82 0.79 5.45 4.14 0.81 5.78 4.46 0.84
6.29 4.78 0.86 6.60 4.95 0.89 7.14 5.43 0.93 7.56 5.74 0.95
118 4.26 3.51 0.65 4.77 3.81 0.68 5.08 4.07 0.70 5.47 4.37 0.71 5.72 4.58 0.74 6.21 4.96 0.77 6.55 5.24 0.79
77 / 64
80 / 67
MM09YJ Indoor Air Temperature :DB / WB
86 / 72 90 / 75
Outdoor
Air Temp.
64 / 53 68 / 57
72 / 61
DB TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
14 6.52 4.95 0.33 7.12 5.42 0.33 7.53 5.72 0.37 8.04 6.11 0.38 8.50 6.46 0.39 8.84 6.72 0.41 9.58 7.28 0.42
17 6.54 4.97 0.38 7.31 5.54 0.39 7.70 5.85 0.38 8.22 6.25 0.40 8.80 6.69 0.41 9.17 6.97 0.43 9.80 7.45 0.44
23 7.06 5.37 0.48 7.65 5.77 0.50 8.12 6.17 0.51 8.64 6.57 0.53 9.30 7.07 0.54 9.70 7.38 0.56 10.23 7.77 0.58
59 8.12 6.17 0.60 8.67 6.63 0.65 9.32 7.09 0.65 9.93 7.55 0.67 10.21 7.76 0.69 11.15 8.47 0.72 11.75 8.93 0.74
70 11.10 7.66 0.
74 11.58 8.17 0.78 12.59 8.68 0.80 13.08 9.03 0.82 13.45 9.28 0.85 14.44 9.96 0.89 15.42 10.64 0.91
75 10.67 7.36 0.81 11.23 7.86 0.86 12.11 8.35 0.87 12.60 8.69 0.89 12.96 8.94 0.92 13.86 9.56 0.95 14.88 10.27 0.99
80 10.22 7.05 0.88 10.93 7.54 0.91 11.63 8.03 0.93 12.16 8.39 0.96 12.63 8.71 0.99 13.46 9.28 1.03 14.40 9.94 1.06
85 9.66 6.66 0.89 10.35 7.14 0.92 11.03 7.61 0.95 11.58 7.99 0.98 12.04 8.31 1.01 12.90 8.90 1.05 13.78 9.51 1.08
90 10.38 7.06 1.05 11.10 7.58 1.08 11.90 8.10 1.11 12.55 8.54 1.14 13.06 8.88 1.18 14.07 9.
57 1.23 14.93 10.15 1.26
95
10.04 6.83 10.90 10.79 7.34 1.11 11.54 7.85 1.14 12.30 8.36 1.18
12.64 8.60 1.22
13.80 9.38 1.27 14.55 9.89 1.30
100 9.29 6.32 1.15 10.23 6.80 1.19 10.72 7.29 1.21 11.44 7.78 1.25 11.86 8.06 1.29 12.87 8.75 1.34 13.58 9.24 1.38
105 8.83 6.00 1.21 9.52 6.48 1.26 10.22 6.95 1.29 10.92 7.42 1.33 11.42 7.77 1.36 12.31 8.37 1.42 13.01 8.85 1.46
110 8.48 5.76 1.26 9.25 6.22 1.27 9.85 6.70 1.31 10.54 7.16 1.35 11.03 7.50 1.40 11.91 8.10 1.45 12.60 8.57 1.49
115 6.65 5.06 0.98 7.22 5.49 1.03 7.78 5.91 1.05
8.33 6.33 1.09 8.74 6.64 1.12 9.45 7.18 1.17 10.00 7.60 1.20
118 5.80 4.64 0.86 6.31 5.04 0.91 6.72 5.38 0.93 7.22 5.78 0.96 7.56 6.05 0.99 8.19 6.55 1.02 8.65 6.92 1.06
64 / 53 68 / 57 72 / 61 77 / 64
80 / 67
Outdoor
Air Temp.
MM12YJ Indoor Air Temperature :DB / WB
90 / 7586 / 72
Figure 214
12K Cooling Capacity Charts
Symbol
DB : Dry Bulb Temperature [ °F}
WB :Wet Bulb Temperature [ °F}
TC: Total Capacity [kBtu/h]
SHC: Sensible Heating Capacity [kBtu/h]
PI: Power Input [kW]
(Comp + indoor fan motor +outdoor fan motor)
Notes
1. All capacities are net, evaporator fan motor heat is deducted.
2. Indicates reference data. When operating at this temperature, these values can be different by operation.
3. Direct interpolation is permissible. Do not extrapolate.
4. Capacities are based on the following conditions:
Interconnecting Piping length 7.5m (24.6 ft) - Level difference of 0 FT
Indoor Air Temperature: 80°F (26.7°C) DB / 67°F (19.4°C) WB
Outdoor Air Temperature: 95°F (35.0°C) DB 75°F (23.9°C) WB
