20 PB

SPECIFICATIONS

Indoor Coil Temperature

Outdoor 65F DB (18C) 68F DB (20C) 73F DB (23C) 79F DB (26C) 80F DB (27C) 82F DB (28C) 86F DB (30C) 90F DB (32C)

Coil air 55F WB (13C) 57F WB (14C) 61F WB (16C) 64F WB (18C) 67F WB (19C) 68F WB (20C) 72F WB (22C) 75F WB (24C)

DB TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC

5F(‑15C) 17848.85 13991.68 19555.07 15336.94 20658.49 16195.97 23081.73 18103.48 23314.87 18286.34 23664.60 18560.64 24254.83 19021.14 26277.76 20604.55

14F(‑10C) 18988.14 14884.77 20803.27 16315.89 21977.12 17229.76 24555.03 19259.02 24803.06 19453.55 25175.10 19745.36 25803.01 20235.25 27955.07 21919.73

23F(‑5C) 21205.42 16624.24 22792.29 17879.18 24379.17 19123.24 27654.00 21689.56 27933.33 21908.64 28352.33 22237.27 29139.79 22855.44 30726.66 24099.51

32F(0C) 22265.69 17455.46 23931.91 18773.14 25598.13 20079.41 29036.70 22774.03 29330.00 23004.08 29769.95 233 49.14 30596.78 23998.21 32263.00 25304.48

41F(5C) 23378.97 18328.23 25128.50 19711.79 26878.03 21083.38 30488.53 23912.74 30796.50 24154.28 31258.44 24516.59 32126.62 25198.12 33876.15 26569.71

50F(10C) 24 5 47.92 19244.64 26384.93 20697.38 28221.93 22137.55 32012.96 25108.37 32336.32 25361.99 32821.37 25742.42 33732.95 26458.03 35569.95 27898.19

59F(15C) 25716.05 2 0169.17 27639.87 21677.46 29563.68 23185.75 32054.96 25133.82 32378.75 25387.70 32864.43 25768.52 35345.99 27721.60 37269.80 29229.89

68F(20C) 29346.30 23020.54 31302.72 24550.90 33259.14 26081.25 35186.21 27596.97 35541.63 27875.72 36074.75 28293.86 38150.19 29923.44 40758.75 31971.16

77F(25C) 28965.89 22723.27 30933.17 24264.61 32900.46 25805.94 34863.40 27346.25 35215.56 27622.48 35743.79 28036.81 37661.09 2 9538.14 40432.68 31707.05

86F(30C) 27465.96 21534.42 29411.51 23064.67 31367.93 24605.89 33894.98 26583.35 34237.35 26851.86 34750.91 27254.64 36682.88 28767.53 39182.75 30727.21

95F(35C) 25900.83 20312.31 27835.51 21831.58 29781.06 23350.96 32280.93 25319.01 32607.00 25574.76 33096.11 25958.38 35595.98 27919.74 37530.66 29439.01

104F(40C) 24542.20 19244.43 26487.75 20774.68 28422.44 22293.95 31441.63 24665.00 31759.22 24914.14 32235.61 25287.85 342 37.3 5 26851.86 36182.90 28371.24

113F(45C) 23183.58 18187.42 25129.13 19706.80 27063.81 21226.07 3010 7. 3 5 2 3607.90 30411.46 23846.37 30867.63 24204.06 32889.59 25794.96 34824.28 27314.23

122F(50C) 22048.85 17295.04 23966.15 18794.78 25563.89 20046.35 28471.78 22334.53 28759.37 22560.13 29190.76 22898.53 31155.99 244 37.48 32913.51 25818.46

TC = TOTAL CAPACITY

SHC = SENSIBLE HEAT CAPACITY

BF = BYPASS FACTOR

Figure 217

36K Cooling Capacity Charts
