117 PB
FIGURE 901
ITEM PART
NUMBER
PART DESCRIPTION USED ON MODEL QTY
1
69700336 Front Panel MWM09Y1J, MWM12Y1J 1
2 69700337 Filter Sub-Assy MWM09Y1J, MWM12Y1J 2
3 69700338 Screw Cover MWM09Y1J, MWM12Y1J 1
4 69700339 Membrane MWM09Y1J, MWM12Y1J 1
5 69700340 Front Case Assy MWM09Y1J, MWM12Y1J 1
6 69700341 Guide Louver MWM09Y1J, MWM12Y1J 1
7 69700342 Helicoid Tongue MWM09Y1J, MWM12Y1J 1
8 69700330 Air Louver MWM09Y1J, MWM12Y1J 2
9 69700343 Shaft of Guide Louver MWM09Y1J, MWM12Y1J 2
10 69700344 Drainage Pipe Sub-assy MWM09Y1J, MWM12Y1J 1
11 69700345 Rear Case assy MWM09Y1J, MWM12Y1J 1
12 69700346 Wall Mounting Frame MWM09Y1J, MWM12Y1J 1
13 69700347 Motor Sub-Assy MWM09Y1J, MWM12Y1J 1
14 69700348 Motor Press Plate MWM09Y1J, MWM12Y1J 1
15 69700349 Cross Flow Fan MWM09Y1J, MWM12Y1J 1
16 69700350 Evaporator Assy MWM09Y1J, MWM12Y1J 1
17 69700351 Temp Sensor Sleeving MWM09Y1J, MWM12Y1J 1
18 69700352 Evaporator Support MWM09Y1J, MWM12Y1J 1
19 68700159 Fan Bearing MWM09Y1J, MWM12Y1J 1
20 69700353 Bearing Holder MWM09Y1J, MWM12Y1J 1
21 69700354 Axil Bush Sub-assy MWM09Y1J, MWM12Y1J 1
22 69700364 Electric Box Assy MWM09Y1J, MWM12Y1J 1
23 69700356 Electric Box Cover Sub-Assy MWM09Y1J, MWM12Y1J 1
24 69700357 Shield Cover MWM09Y1J, MWM12Y1J 1
25 69700358 Crank MWM09Y1J, MWM12Y1J 1
26 69700359 Stepping Motor MWM09Y1J, MWM12Y1J 1
27 69700293 Indicator Shield Cover MWM09Y1J, MWM12Y1J 1
28 69700294 Indicator Light Cover MWM09Y1J, MWM12Y1J 1
29 69700295 Display Board MWM09Y1J, MWM12Y1J 1
30 69700365 Electric Box Sub-Assy MWM09Y1J 1
30a 69700360 Electric Box Sub-Assy MWM12Y1J 1
31 69700361 Main Board MWM09Y1J, MWM12Y1J 1
32 69700130 Terminal Board MWM09Y1J, MWM12Y1J 1
33 69700313 Remote Controller MWM09Y1J, MWM12Y1J 1
34 69700362 Temperature Sensor MWM09Y1J, MWM12Y1J 1
35 69700363 Temperature Sensor MWM09Y1J, MWM12Y1J 1
-ITEMS ARE NON- ILLUSTRATED
*ITEMS ARE NON-STOCKED, WILL NORMALLY REQUIRE 2-3 WEEKS LEAD TIME
PARTS CATALOG
Indoor Unit MWM09Y1J, MWM12Y1J
