PARTS CATALOG
Indoor Unit MWM36YJ3
Figure 903
ITEM PART NUMBER PART DESCRIPTION USED ON MODEL QTY
1 69700592 Receiver Window MWM36YJ3 I
2 69700593 Front Panel MWM36YJ3 1
3 69700594 Stand bar MWM36YJ3 1
4 69700595 Filter Sub-Assy MWM36YJ3 2
5 69700596 Front Case Sub-Assy MWM36YJ3 1
6 69700597 Upper Guide Louver MWM36YJ3 1
7 69700598 Lower Guide Louver MWM36YJ3 1
9 69700599 Air Louver 2 MWM36YJ3 2
10 69700600 Air Louver 1 MWM36YJ3 16
11 69700601 Connecting Rod MWM36YJ3 2
12 69700602 Louver Clamp MWM36YJ3 9
13 69700603 Water Tray MWM36YJ3 1
14 69700604 Screw Cover MWM36YJ3 4
15 69700605 Rubber Plug (Water Tray) MWM36YJ3 1
16 69700606 Rear Case Sub- Assy MWM36YJ3 I
17 69700607 Cross Flow Fan 1 MWM36YJ3 1
19 69700608 Cross Flow Fan 2 MWM36YJ3 1
21 69700609 Left Evaporator Support MWM36YJ3 1
22 69700610 Evaporator Assy MWM36YJ3 1
23 69700611 Wall Mounting Frame MWM36YJ3 1
25 69700612 Fan Motor MWM36YJ3 1
26 69700613 Pipe Clamp MWM36YJ3 1
27 69700614 Drainage Hose MWM36YJ3 1
29 69700615 Cover Plate MWM36YJ3 1
30 69700616 MotorFixed Clip/ Motor Retainer MWM36YJ3 1
31 69700617 Step Motor MWM36YJ3 1
36 69700618 Electric Box Assy/ PCB Board Box MWM36YJ3 1
38 69700620 Terminal Board MWM36YJ3 1
39 69700621 Main Board MWM36YJ3 1
40 69700622 Display Board MWM36YJ3 1
-43 69700623 Remote Control MWM36YJ3 1
44 69700625 Tube Sensor MWM36YJ3 1
45 69700626 Ambient Temperature Sensor MWM36YJ3 1
-46 69700619 Transformer MWM36YJ3
-ITEMS ARE NON- ILLUSTRATED
*ITEMS ARE NON-STOCKED, WILL NORMALLY REQUIRE 2-3 WEEKS LEAD TIME
