Figure 904
ITEM PART
NUMBER
PART DESCRIPTION USED ON MODEL QTY
1 69700000 Front Grill MRM09Y1J, MRM12Y1J 1
2 69700273 Cabinet MRM09Y1J, MRM12Y1J 2
3 69700280 Axial Flow Fan MRM09Y1J, MRM12Y1J 1
4 69700281 Fan Motor MRM09Y1J, MRM12Y1J 1
5 69700270 Chassis Sub-assy MRM09Y1J, MRM12Y1J 1
6 69700164 Drainage Connecter MRM09Y1J, MRM12Y1J 1
7 69700284 Compressor Gasket MRM09Y1J, MRM12Y1J 1
8 69700268 Compressor and Fittings MRM09Y1J, MRM12Y1J 2
9 69700288 Electric Expansion Valve Sub MRM09Y1J 2
9a 69700009 Electric Expansion Valve Sub MWM12Y1J 2
10 69700289 Valve Cover MRM09Y1J 1
10a 69700010 Valve Cover MWM12Y1J 1
11 69700009 Valve MRM09Y1J 1
11a 69700011 Valve MWM12Y1J 1
12 69700010 Valve MRM09Y1J 1
12a 69700276 Valve MWM12Y1J 1
13 69700011 Valve Support MRM09Y1J 1
13a 69700272 Valve Support MWM12Y1J 1
14 69700286 Cable Cross Plate 2 MRM09Y1J 1
14a 69700014 Cable Cross Plate 2 MWM12Y1J 1
15 69700276 Cable Cross Plate 1 MRM09Y1J 1
15a 69700283 Cable Cross Plate 1 MWM12Y1J 1
16 69700272 Right Side Plate Assy MRM09Y1J 1
16a 69700279 Right Side Plate Assy MWM12Y1J 1
17 69700014 Cover of Pass Wire MRM09Y1J 1
17a 69700278 Cover of Pass Wire MWM12Y1J 1
18 69700291 Electric Expand Valve Fitting MRM09Y1J 1
18a 69700213 Electric Expand Valve Fitting MWM12Y1J
19 69700283 Temperature Sensor MRM09Y1J, MRM12Y1J 1
20 69700278 4-Way Valve Assy MRM09Y1J 1
20a 69700274 4-Way Valve Assy MWM12Y1J 1
21 69700213 Magnet Coil MRM09Y1J 1
21a 69700269 Magnet Coil MWM12Y1J 1
22 69700285 Compressor Overload MRM09Y1J 1
22a 67700271 Compressor Overload MWM12Y1J 1
23 69700274 Rear Grill MRM09Y1J 1
23a 69700025 Rear Grill MWM12Y1J 1
24 69700269 Condenser Assy MRM09Y1J 1
PARTS CATALOG
Outdoor Unit MRM09Y1J, MRM12Y1J
