Figure 905

ITEM PART

NUMBER

PART DESCRIPTION USED ON MODEL QTY

1 69700258 Compressor and ttings MRM18Y3J 1

2 69700259 Condenser Assy MRM18Y3J 1

3 69700233 Clapboard Sub-Assy MRM18Y3J 1

4 69700234 Coping MRM18Y3J 1

5 69700235 Left Side Plate MRM18Y3J 1

6 69700236 Right Side Plate MRM18Y3J 1

7 69700260 Capacitor Clamp Sub-assy MRM18Y3J 1

8 69000237 Electric Box (Fireproong) MRM18Y3J 1

9 69700238 Cabinet Assy MRM18Y3J 1

10 69700239 Rear Grill MRM18Y3J 1

11 69700240 Front Grill MRM18Y3J 1

12 69700241 Motor Support Sub-Assy MRM18Y3J 1

13 69700242 Valve Support Assy MRM18Y3J 1

14 69700261 Supporting Board(Condenser) MRM18Y3J 1

15 69700243 Handle Assy MRM18Y3J 1

16 69700262 Electric Box Assy MRM18Y3J 1

17 69700263 Chassis Sub-assy MRM18Y3J 1

18 69700264 Capillary Sub-assy MRM18Y3J 1

19 69700265 4-Way Valve Assy MRM18Y3J 1

-ITEMS ARE NON- ILLUSTRATED

*ITEMS ARE NON-STOCKED, WILL NORMALLY REQUIRE 2-3 WEEKS LEAD TIME

PARTS CATALOG

Outdoor Unit MRM18Y3J
