PARTS CATALOG
Outdoor Unit MRM24Y3J
Figure 906
ITEM PART
NUMBER
PART DESCRIPTION USED ON MODEL QTY
1 69700231 Compressor and ttings MRM24Y3J 1
2 69700232 Condenser Assy MRM24Y3J 1
3 69700233 Clapboard Sub-Assy MRM24Y3J 1
4 69700234 Coping MRM24Y3J 1
5 69700235 Left Side Plate MRM24Y3J 1
6 69700236 Right Side Plate MRM24Y3J 1
7 69000237 Elec tric Box (Fireproong) MRM24Y3J 1
8 69700238 Cabinet Assy MRM24Y3J 1
9 69700239 Rear Grill MRM24Y3J 1
10 69700240 Front Grill MRM24Y3J 1
11 69700241 Motor Support Sub-Assy MRM24Y3J 1
12 69700242 Valve Support Assy MRM24Y3J 1
13 69700243 Handle Assy MRM24Y3J 1
14 69700244 Electric Box Assy MRM24Y3J 1
15 69700245 Chassis Sub-assy MRM24Y3J 1
16 69700246 4-Way Valve Assy MRM24Y3J 1
17 69700164 Drainage Connecter MRM24Y3J 1
18 69700165 Cut off Valve MRM24Y3J 1
19 69700247 Cut off Valve Sub-Assy MRM24Y3J 1
20 69700248 Electronic Expansion Valve assy MRM24Y3J 1
21 69700249 Axial Flow Fan MRM24Y3J 1
22 69700250 FanMotor MRM24Y3J 1
23 69700251 Insulated Board (Cover of Electric
Box)
MRM24Y3J 1
24 69700252 LeftHandle MRM24Y3J 1
25 69700253 Capacitor MRM24Y3J 1
26 69700254 Capacitor MRM24Y3J 1
27 69700255 Temperature Sensor MRM24Y3J 1
28 69700030 Terminal Board MRM24Y3J 1
29 69700256 Elecric Expansion valve tting MRM24Y3J 1
30 69700257 Reactor MRM24Y3J 1
-ITEMS ARE NON- ILLUSTRATED
*ITEMS ARE NON-STOCKED, WILL NORMALLY REQUIRE 2-3 WEEKS LEAD TIME
