23 PB
SPECIFICATIONS
Figure 222
36K Heating Capacity Charts
Indoor Coil Temperature
Outdoor 65F DB (18C) 68F DB (20C) 73F DB (23C) 79F DB (26C) 80F DB (27C) 82F DB (28C) 86F DB (30C)
Coil air 55F WB (13C) 57F WB (14C) 61F WB (16C) 64F WB (18C) 67F WB (19C) 68F WB (20C) 72F WB (22C)
DB TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
‑4F 17683.54 17683.54 17515.03 17515.03 17220.13 17220.13 16735.12 16735.12 16718.38 16718.38 16651.51 16651.51 16525.00 16525.00
0F 19158.05 19158.05 18979.00 18979.00 18663.04 18663.04 18121.89 18121.89 18103.77 18103.77 18031.36 18031.36 17894.19 17894.19
6F 20211.27 20211.27 20021.69 20021.69 19684.66 19684.66 19122.87 19122.87 19103.75 19103.75 19027.33 19027.33 18873.68 18873.68
10F 21053.84 21053.84 20853.73 20853.73 20506.17 20506.17 19915.31 19915.31 19895.40 19895.40 19815.82 19815.82 19663.59 19663.59
16F 21685.77 21685.77 21485.66 21485.66 21127.57 21127.57 20509.64 20509.64 20489.14 20489.14 20407.18 20407.18 20253.40 20253.40
19F 22117.59 22117.59 21896.42 21896.42 21538.32 21538.32 20905.87 20905.87 20884.96 20884.96 20801.42 20801.42 20643.09 20643.09
24F 24571.59 24571.59 24360.95 24360.95 23992.32 23992.32 23345.75 23345.75 23322.41 23322.41 23229.12 23229.12 23107.62 23107.62
32F 27436.35 27436.35 27225.70 27225.70 26857.08 26857.08 26181.86 26181.86 26155.68 26155.68 26051.06 26051.06 25972.37 25972.37
41F 30711.86 30711.86 30501.22 30501.22 30143.12 30143.12 29424.61 29424.61 29395.19 29395.19 29277.61 29277.61 29247.88 29247.88
43F 31533.37 31533.37 31322.73 31322.73 30954.10 30954.10 30237.91 30237.91 30207.67 30207.67 30086.84 30086.84 30069.40 30069.40
47F 34387.59 34387.59 34040.03 34040.03 33450.23 33450.23 32448.41 32448.41 32415.96 32415.96 32286.29 32286.29 31996.79 31996.79
53F 34735.15 34735.15 34377.06 34377.06 33776.73 33776.73 32771.64 32771.64 32738.87 32738.87 32607.91 32607.91 32312.75 32312.75
59F 35525.07 35525.07 35166.97 35166.97 34545.58 34545.58 33511.95 33511.95 33478.43 33478.43 33344.52 33344.52 33050.00 33050.00
64F 36283.39 36283.39 35914.76 35914.76 35282.83 35282.83 34231.40 34231.40 34197.17 34197.17 34060.38 34060.38 33755.66 33755.66
70F 36967.98 36967.98 36588.82 36588.82 35956.89 35956.89 34877.87 34877.87 34842.99 34842.99 34703.62 34703.62 34398.12 34398.12
75F 37484.06 37484.06 37104.90 37104.90 36451.90 36451.90 35367.93 35367.93 35332.56 35332.56 35191.23 35191.23 34872.07 34872.07
78F 37831.62 37831.62 37441.93 37441.93 36788.93 36788.93 35691.16 35691.16 35655.47 35655.47 35512.85 35512.85 35198.57 35198.57
TC = TOTAL CAP[ACITY
SHC = SENSIBLE HEAT CAPACITY
BF = BYPASS FACTOR
