Friedrich VRP Series User Manual

6
Electrical Data
MCA = Minimum Circuit Ampacity
MOP / MOCP - Maximum Overcurrent Protection / Breaker Size
Minimum Circuit Amps (MCA) and MOCP values in the above table are calculated in accordance with The NEC.Article 440
Electrical Requirements
Wire Size Use ONLY wire size recommended for
single outlet branch circuit.
Fuse/Circuit
Breaker
Use ONLY type and size fuse or HACR cir-
cuit breaker indicated on unit’s rating guide.
Proper over current protection to the units is
the responsibility of the owner.
Grounding Unit MUST be grounded from branch circuit
to unit, or through separate ground wire
provided on permanently connected units.
Ensure that branch circuit or general pur-
pose outlet is grounded.
Wire Sizing Use recommended wire size given in tables
and install a single branch circuit. All wiring
must comply with local and national codes.
NOTE: Use copper conductors only.
Electrical Rating Table
NOTE: Use copper conductors ONLY. Wire sizes are per NEC.
Recommended Branch Circuit Sizes*
Nameplate Maximum Circuit Breaker Size AWG Wiring Size**
15A 14
20A 12
30A 10
AWG - American Wire Gauge
* Single circuit from main box.
** Based on 100’ or less of copper, single insulated conductor at 60˚ C
NOTE: All eld wiring must comply with NEC and local codes. It is the installer’s responsibility to ensure that the electrical codes are
met.
VRP Model Voltage
Electric
Heater
Watts
Electric
Heating
Btu
ID Blower
Amps
OD Blower
Amps
Total
Electric
Heating
Amps
MCA MOP / MOCP
VRP12K
230 2500 8530 0.34 0.42 11.2
14.0 15
208 2030 6980 0.38 0.42 10.2
230 3400 11601 0.34 0.42 15.1
18.9 20
208 2780 9480 0.38 0.42 13.8
230 5000 17060 0.34 0.42 22
27.5 30
208 4100 13980 0.38 0.42 20.1
VRP12R 265
2500 8530 0.2 0.40 9.8 12.3 15
3400 11601 0.2 0.40 13.2 16.5 20
5000 17060 0.2 0.40 19.3 24.1 25
VRP24K
230 2500 8530 0.77 0.60 11.6
14.5 15
208 2030 6980 0.85 0.60 10.7
230 3400 11600 0.77 0.60 15.6
19.5 20
208 2780 9480 0.85 0.60 14.3
230 5000 17050 0.77 0.60 22.6
28.3 30
208 4100 13980 0.85 0.60 20.6
230 7500 25590 0.77 0.60 33.4
41.8 45
208 6130 20900 0.85 0.60 30.4
230 10000 34120 0.77 0.60 44.3
55.4 60
208 8180 27890 0.85 0.60 40.2
VRP24R 265
2500 8530 0.7 0.60 10.8 13.5 15
3400 11601 0.7 0.60 14.2 17.8 20
5000 17060 0.7 0.60 20.3 25.4 25
7500 25590 0.7 0.60 29.7 37.1 40
10000 34120 0.7 0.60 39.1 48.9 60
