Friedrich YM18J34A - Page 43

TTJ-0198 (10/97) (Page 43 of 64)
"YS" - "YM" - "YL" SERIES PARTS LIST
REF. PART NO. DESCRIPTION APPLICATION
YYYY
SSML
0112
9384
JJJJ
1333
0345
AA
CHASSIS PARTS (Cont.)
19 618-207-00 Strap, Capacitor ............................................................................. 1 1 1 1
20 618-233-00 Decorative Panel ............................................................................ 1 1 1 1
* 618-076-00 Grommet, Suction Line................................................................... 1 1 1 1
* 618-148-00 Connector, Fresh Air & Exhaust ..................................................... 1 1 1
* 618-148-01 Connector, Fresh Air & Exhaust ..................................................... 1
21 618-172-00 Cover, Top ...................................................................................... 1 1 1
21 618-179-00 Cover, Top ...................................................................................... 1
22 618-167-00 Insulation, Top Cover ...................................................................... 1 1 1
22 618-182-00 Insulation, Top Cover ...................................................................... 1
23 618-171-00 Deck ............................................................................................... 1 1 1
23 618-180-00 Deck ............................................................................................... 1
* 608-658-08 Filter, Air ......................................................................................... 1 1
* 608-658-09 Filter, Air ......................................................................................... 1
* 608-658-10 Filter, Air ......................................................................................... 1
* 618-230-00 Holder, Filter................................................................................... 2 2 2 2
24 618-202-00 Airfoil .............................................................................................. 1 1 1
24 618-202-01 Airfoil .............................................................................................. 1
* 618-206-00 Bracket, Resistor Block .................................................................. 1 1 1 1
* 915-003-02 Clamp, Supply Cord .......................................................................
25 605-420-03 Fan Blade ....................................................................................... 1 1
25 605-420-04 Fan Blade ....................................................................................... 1
25 605-420-01 Fan Blade ....................................................................................... 1
26 606-106-03 Blower Wheel ................................................................................. 1 1
26 606-106-05 Blower Wheel ................................................................................. 1
26 606-106-02 Blower Wheel ................................................................................. 1
27 618-033-00 Inner Wall ....................................................................................... 1 1
27 618-047-00 Inner Wall ....................................................................................... 1
27 618-066-00 Inner Wall ....................................................................................... 1
28 618-025-00 Mount, Motor .................................................................................. 1 1
28 618--041-00 Mount, Motor .................................................................................. 1
28 618-067-00 Mount, Motor .................................................................................. 1
29 618-036-00 Shroud ........................................................................................... 1 1
29 618-049-00 Shroud ........................................................................................... 1
29 618-077-00 Shroud ........................................................................................... 1
30 618-026-00 Brace, Shroud ................................................................................ 3 3 3
30 618-100-00 Brace, Shroud ................................................................................ 3
31 618-169-00 Insulation, Inner Wall ...................................................................... 1 1
31 618-169-01 Insulation, Inner Wall ...................................................................... 1
31 618-169-02 Insulation, Inner Wall ...................................................................... 1
32 618-173-00 Blower Front ................................................................................... 1
32 618-173-01 Blower Front ................................................................................... 1
32 618-074-01 Blower Front ................................................................................... 1
* Not Shown
