Friedrich YM18J34A - Page 44

TTJ-0198 (10/97) (Page 44 of 64)
"YS" - "YM" - "YL" SERIES PARTS LIST
REF. PART NO. DESCRIPTION APPLICATION
YYYY
SSML
0112
9384
JJJJ
1333
0345
AA
CHASSIS PARTS (Cont.)
32 618-178-01 Blower Front ................................................................................... 1
33 618-149-00 Scroll .............................................................................................. 1 1
33 618-175-00 Scroll .............................................................................................. 1
33 618-181-00 Scroll .............................................................................................. 1
34 618-215-00 Door, Slide Assembly ..................................................................... 1 1 1 1
35 618-090-01 Base Pan........................................................................................ 1 1
35 618-090-09 Base Pan........................................................................................ 1
35 618-095-01 Base Pan........................................................................................ 1
* 618-038-00 Drain Pan ....................................................................................... 1 1 1
* 618-074-00 Drain Pan ....................................................................................... 1
* 601-799-00 Bellows, Drain Valve ....................................................................... 1 1 1 1
* 618-188-00 Grille Assembly (Rear) ................................................................... 1 1
* 618-188-01 Grille Assembly (Rear) ................................................................... 1
* 618-188-02 Grille Assembly (Rear) ................................................................... 1
* 618-248-00 Thermostat Holder ......................................................................... 1 1 1 1
36 610-289-00 Grommet, Compressor................................................................... 3 3 3
36 01150934 Grommet, Compressor................................................................... 3
37 914-004-00 Screw, Compressor Mounting ........................................................ 3 3 3 3
38 618-102-00 Plenum Assembly .......................................................................... 1 1 1
38 618-105-00 Plenum Assembly .......................................................................... 1
* 618-093-00 Knob, Fresh Air & Exhaust ............................................................. 1 1 1 1
* 618-062-00 Connector, Louver .......................................................................... 2 2 2
* 618-096-00 Connector, Louver .......................................................................... 2
* 618-063-00 Louver ............................................................................................ 20 20 20
* 618-097-00 Louver ............................................................................................ 20
* 618-063-01 Louver with Handle......................................................................... 2 2 2
* 618-097-01 Louver with Handle......................................................................... 2
* 618-092-00 Lever, Fresh Air & Exhaust ............................................................. 1 1 1 1
39 618-257-00 Outer Shell Assembly ..................................................................... 1 1
39 618-257-01 Outer Shell Assembly ..................................................................... 1
39 618-257-02 Outer Shell Assembly ..................................................................... 1
40 618-084-03 Sill Plate ......................................................................................... 1 1 1
40 618-084-01 Sill Plate ......................................................................................... 1
41 618-089-00 Grille, Intake ................................................................................... 1 1
41 618-111-00 Grille, Intake ................................................................................... 1
41 618-104-00 Grille, Intake ................................................................................... 1
* 618-199-00 Latch, Grille .................................................................................... 2 2 2 2
42 602-944-08 Wingboard...................................................................................... 1 1
42 602-944-09 Wingboard...................................................................................... 1
42 602-944-10 Wingboard...................................................................................... 1
* 611-050-04 Accessory Package........................................................................ 1 1
