EN
FRIGOMAT GX4Kompact, GX6, GX8 M04.42026 R.2019.05.30 13
Esploso operatore, kit accessori/ricambi in dotazione
Cover - Insulating ring rubber - Beater - Scoop
Drain cylinder plugs
Supplied kit
N. COD. DESCRIPTION
N. COD. DESCRIPTION
1 Z65.43178 Cover 9 P12.41981 Scoop
2 B60.41993 Cover pin 10 B50.43164 Cylinder drain plug (short)
3 L18.37559 Knob Beater
11 B50.43166 Cylinder drain plug (long)
4 P02.40443 O-Ring knob beater 12 P02.40444 O-Ring cylinder drain plug
5 Z70.41914 Beater 13 P13.002 Small Brush
6 P18.37729 Scraper 14 P13.001 Medium Brush
7 P13.43152 Insulating ring rubber 15 P13.007 O-R disassembler
8 P02.43352 Insulating ring rubber Gasket
- - -
n.24
2
1
3
4
5
6
8
7
10
13
14
15
12
11
9
12
