Fritz! FRITZ!Box 7490 User Manual

Establishing a Wireless LAN Connection Using WPS
FRITZ!Box 7490 29
2. Open the wireless LAN software on the computer.
In Windows 8 and 7, for instance, click the wireless LAN
symbol in the task bar.
3. Select the wireless radio network of the FRITZ!Box.
The preconfigured name of the wireless LAN radio net-
work is “FRITZ!Box Fon WLAN 7490”.
4. Click “Connect”.
The field for the network key appears, along with the in-
formation that you can establish the connection by
pressing a button on the router:
5. For this step you have two minutes: Press the “WLAN”
button on the FRITZ!Box and hold it down until the
“WLAN” LED begins flashing.
The wireless LAN connection will be established.
WLAN
DECT
WPS
Power / DSL
Internet
Festnet z
WLAN
Info

Fritz! FRITZ!Box 7490 Specifications

General

Model	FRITZ!Box 7490
Category	Network Router
Type	DSL Router
Wireless Standard	IEEE 802.11 a/b/g/n/ac
WLAN Frequency Bands	2.4 GHz, 5 GHz
WLAN Data Transfer Rate (2.4 GHz)	Up to 450 Mbps
WLAN Data Transfer Rate (5 GHz)	Up to 1300 Mbps
DSL Standard	VDSL2, ADSL2+
DSL Data Rate (VDSL2)	Up to 100 Mbps
DSL Data Rate (ADSL2+)	Up to 24 Mbps
Ethernet Ports	4 x Gigabit Ethernet
USB Ports	2 x USB 3.0
DECT	Yes
Firewall	Yes
VPN	Yes
Telephony	VoIP, Analog, ISDN
Ports	1 x DSL, 2 x USB
