Dynamic 2100 Battery Strapping Tool Operation Manual | FPA001 | Apr 2018 | Page 11
6.4 Possible troubleshooting causes and remedies
Troubleshooting
Tool Trouble
Possibilities
Solution
Tool doesn’t work at all
Battery is empty or
defective
Charge or replace battery
Contact problems caused
by broken battery housing
Replace battery
Contact problems caused
by a damaged insertation
part N5.4343 or damaged
motor housings P32.1132
and P32.1133
Replace cover insertation
part or motor housing
Defective busbar
P32.1136/37
Replace busbar
Contact problem of the
internal wires
Check contacts and fix
them if required or change
defective parts
Defective circuit board
Replace circuit board
Tool doesn’t tension
Tensioning wheel is dirty
or worn
Clean tensioning wheel or
replace it, don’t use any
hard objects for this
P32.1051 is not meshing
with P32.1048 because
spring N2.5822 is
defective or parts are dirty
Replace spring N2.5822,
clean dirty parts
Faulty tensioning when or
tensioning wheel is
assembled reversed
Correct assembling
Grippers are dirty, worn, or
wrongly assembled
Replace grippers, clean
them or assemble correct,
don’t use any hard objects
for this
Gearing parts from the
tensioning gear are
defective
Loose pinion in planet
shaft
Loose pinion on tensioning
motor
Check tensioning gear and
replace defective parts
Defective tensioning motor
Replace tensioning motor
Defective circuit board
Replace circuit board
