Dynamic 2100 Battery Strapping Tool Operation Manual | FPA001 | Apr 2018 | Page 12
Tool Trouble
Possibilities
Solution
Micro switch N5.2322 for
tensioning is defective
Replace micro switch
Contact problem of the
internal wires
Replace micro switch
Defective gear bearings
Replace bearings
Defective tensioning body
Replace tensioning body
Needle free wheeling
assembled reversed
Correct assembling
Tensioning wheel turns
back immediately after the
tensioning cycle
Shaft P32.1014 in lever
P32.1051 is loose
Check parts and replace
as required
Defective needle free
wheeling N3.4509
Check parts and replace
as required
Tool doesn’t weld
Welding gripper P32.1511
is dirty or worn
Replace or clean welding
gripper, don’t use any hard
objects for this
Welding stop gripper is
dirty or worn
Replace or clean welding
stop gripper, don’t use any
hard objects for this
Damaged housing parts
Replace housing parts
Defective circuit board
Replace circuit board
Defective welding motor
Replace welding motor
Pressure spring N2.5294
defective
Replace pressure spring
Loose pinion P32.1119 om
welding motor
Replace pinion
Gearing parts of the
welding gear are defective
Check welding gear and
replace defective parts
Micro switch N5.2322 for
welding is defective
Replace micro switch
Defective busbar
P32.1108
Replace busbar
Contact problem of the
internal wires
Check contacts and fix
them if required or change
defective parts
Defective gear bearing
Replace bearing
