MACHINE MAKE – UP
CARRIAGE
16.8667
Carriage 0 / Mechanical film-core tension. For pre-stretched film
16.8660
Carriage 1 / Mechanical film-core tension <01-05-2013 Version 01-02-03
16.8660
Carriage 1 / Mechanical film-core tension >01-05-2013 Version 04
16.8661
Carriage 2 / Mechanical break-roll tension
16.8663
Carriage 4 / Magnetically brake system
VARIATION
16.8670
Gearbox fixed position
16.8671
Gearbox with shock-absorber
OPTIONS
16.8280
Ramp turntable Ø1.500mm, length 1.494mm, Height 71,5mm, 1.000kg*
16.8211
Ramp turntable Ø1.650mm, length 1.550mm, Height 71,5mm, 1.250kg*
16.8212
Ramp turntable Ø1.650mm, length 1.550mm, height 71,5mm, 2.000kg*
16.8214
Ramp turntable Ø1.800mm, length 1.550mm, height 71,5mm, 2.000kg*
16.8216
Ramp turntable Ø1.650mm, length 1.850mm, height 71,5mm, 2.000kg*
16.8218
Ramp turntable Ø1.800mm, length 1.850mm, height 71,5mm, 2.000kg*
16.8221
Ramp turntable Ø2.200mm, length 1.850mm, height 71,5mm, 2.000kg*
N5.2638
Standard photocell for black film
N5.2651
Special photocell for black goods
*NOTE!!
Ramps KG refers to maximal loading capacity on the ramp
