Fromm FS360 Series - Safety Devices on Control Panel; Control Panel Safety Components

SERVICE MANUAL FS360_EN01 Version00.doc FROMM
For further updates, see our website www.fromm-stretch.com and Login!
It is forbidden to duplicate this manual or parts thereof or any other form without the author’s authorisation © 2018
17
SAFETY DEVICES
We would like to again highlight how all safety devices have been installed for operator safety,
etc. and must not be manipulated or excluded from the operations.
Refer to the drawings below and to the notes applied.
Observe the control panel
A = Acoustic signal
B = Emergency stop button
C = Main switch
R= Reactivation button
Main switch:
The power (1x230V) is supplied
by turning on the main switch.
The voltage for the various control
parts (24Vdc) is also supplied by
turning on the machine.
D= Anti-crushing device
E = Parachute system
A
C
R
B
A
B
R
C
