FUNCTIONS CONTROL
8. Check the functionality of the Photocell (Fig.1)
Fig. 1
9. Check the functionality of CARRIAGE MOVEMENT (Fig.1 / 2 / 3)
Fig.1 / Manual movement
Fig.2 / Movement UP
Fig.3 / Movement DOWN
10. Check the functionality of Potentiometers (Fig.1 / 2 / 3)
Fig.1
Fig.2
Fig.3
11. Check the functionality of Potentiometers (Fig. 1) and selectors (Fig. 2 / 3)
Fig.1
Fig.2
Fig.3
