[ ] = Group * = Wearing parts
3-3
[P32.0205] P32.0208 1 IDLER STEP C13
[P32.0206] P32.0208 1 LEVER C16
[P32.0207] P32.0208 1 GEAR BODY B3+
[P32.0208] P32.0201/17 1 GEAR B13
[P32.0209] P32.0201/17 1 GEAR WHEEL C17
[P32.0210] P32.0201/17 1 GEAR WHEEL B23
[P32.0211] P32.0201/17 1 CONICAL GEAR WHEEL D23
[P32.0212] P32.0201/17 1 GEAR WHEEL D21
P32.0213 * P32.0201/17 1 MOTOR D21
[P32.0221] 1 COVER A4
[P32.0222] 1 END COVER D4
P32.1022 P32.0202 1 WELDING EXCENTRIC A15
P32.1024 P32.0144 1 ROCKER A16
P32.1027 P32.0201/17 1 BALL CAGE C10
P32.1028 P32.0201/17 1 BOLT D11
P32.1029 P32.0201/17 1 THRUST PIECE C10
P32.1032 P32.0201/17 1 DRIVING PIN D11
P32.1035 P32.0201/17 2 DRIVER D10+
P32.1215 P32.0201/17 1 HANDLE SHAFT C19
P32.1251 P35.0146 1 PUSHER B12
P32.1511 * P32.0201/17 1 WELDING GRIPPER D11
P32.1710 1 CENTERING SLEEVE C12
P32.2009 P32.8148/51 2 TURNING BUTTON C20
P32.2012 P32.0201/17 1 GUIDE B16
P32.2016 P33.0204 1 GEAR WHEEL C17
P32.8101 P32.0200 1 BODY C7
[P32.8103] P32.0201/17 1 MOTOR HOUSING A22
P32.8106 1 STEEL INSERT D9
P32.8107 * 1 WELDING STOP GRIPPER C10
P32.8108 1 HOLDER C3
P32.8115 P32.0202 1 PINION A14
P32.8116 P32.0203 1 SPRING SLIDE A9
P32.8117 P32.0203 1 SPRING BOLT B8
P32.8118 1 STRAP GUIDE PLATE A3
P32.8120 P32.0201/17 1 MAGNET D7
P32.8121 P32.0201/17 1 ECCENTRIC SHAFT C7
P32.8122 P32.0201/17 1 TOOTHED BELT PULLEY B9
P32.8125 P32.0201/17 1 PUSHER B14
P32.8126 P32.0204 1 GEAR WHEEL C15
P32.8127 P32.0205 1 PLANET SHAFT C14
P32.8128 P32.0205 1 GEAR WHEEL C13
P32.8129 P32.0208 1 GEAR WHEEL D16
P32.8130 P32.0206 1 LEVER C16
P32.8131 P32.0207 1 GEAR BODY C17
P32.8132 P32.0208 1 GEARING COVER D15
P32.8134 P32.0209 1 GEAR WHEEL D17
P32.8135 P32.0210 1 GEAR WHEEL B24
P32.8136 P32.0201/17 1 HOUSING B24
P32.8137 P32.0200 1 SWIVEL SHAFT A18
P32.8138 P32.0211 1 CONICAL GEAR WHEEL D22
P32.8139 P32.0212 1 GEAR WHEEL D21
P32.8140 P32.0201/17 1 RETAINER A22
P32.8141 P32.0201/17 1 COVERING B21
P32.8142 P32.0201/17 1 HANDLE LEVER B21
Item-No. in group Pcs. Description Dimension Field
